NB Semiplate Ni 100 - 1.00 l - EUD/EVE!

NB Semiplate NIMN 100 Nickel-Manganese Plating Solution   General Information NB Semiplate NIMN 100 is a nickelsulfamate electroplating process, which incorporates small amounts of Mn in the deposit. While properties of pure Ni deposits change dramatically during temperature treatments, the Mn content stabilises the hardness, ductility and yield strength under temperature treatments as high as 600°C. Secondly, such properties do not dramatically change in operation. Therefore, the process is well suited for Ni films used for micro-electromechanical functions, as required for sensors and actuators in microsystem technology. The process can be operated for rather columnar growth without grain refiner and rather rough surface condition; this is the ready-to-use product status of NB Semiplate NIMN 100 or for fine-grained films and semi-rough surface using the grain refiner NI 100 ADD. AGENT NB Semiplate NIMN 100 is manufactured to meet the requirements associated with the electroforming processes for the semiconductor industry and microsystem technology (MST). The NB Semiplate NIMN 100 process contains an anode activating agent in controlled amounts to enhance anode corrosion and prevent anode passivation. Deposit properties are easy to control and maintain. NOTE: NB Semiplate NIMN 100 is a ready-to-use product. It is not necessary to add other materials for the initially start of the application. Over time, it may be necessary depending on the electrolyte and application to add additives (see data sheet). With adjusted photoresist processing, the NB Semiplate NINM 100 is compatible with common AZ®- and TI resists. Product Properties High purity nickel depositions High stability of mechanical properties under temperature and in operation High ductility High hardness Fine grained or large grained Medium mechanical stress impact of Mn incorporation (depending on operation condition) No anode passivation Good throwing power Further Information MSDS: Safety Data Sheet NB Semiplate NIMN 100 english Sicherheitsdatenblatt NB Semiplate NIMN 100 german TDS: Technical Data Sheet NB Semiplate NIMN 100 english Application Notes: Instruction NBT Sample Service for Plating Baths english Anleitung NBT Probenservice für Galvanikbäder german Plating Theory english Galvanik Theorie german Plating and Photoresist english Galvanik und Fotolacke german Further Information about Processing

NB Semiplate AG 100 Silver Plating Solution   General Information NB Semiplate AG 100 is an alkaline, non-cyanide electroplating formulation, which produces satin bright silver deposits. Deposits from the NB Semiplate AG 100 have excellent physical characteristics such as solder ability and good electrical conductivity. NOTE: NB Semiplate AG 100 is a ready-to-use product. It is not necessary to add other materials for the initially start of the application. Over time, it may be necessary depending on the electrolyte and application to add additives (see data sheet). With adjusted photoresist processing, the NB Semiplate AG 100 is compatible with common AZ®- and TI resists. Product Properties Purity: approx. 99.0 – 99.9 Hardness: approx. 70 to 90 HV0,020 Density: approx. 10.4 g/cm3 Further Information MSDS: Safety Data Sheet NB Semiplate AG 100 english Sicherheitsdatenblatt NB Semiplate AG 100 german TDS: Technical Data Sheet NB Semiplate AG 100 english Application Notes: Instruction NBT Sample Service for Plating Baths english Anleitung NBT Probenservice für Galvanikbäder german Plating Theory english Galvanik Theorie german Plating and Photoresist english Galvanik und Fotolacke german Further Information about Processing

NB Semiplate AU 100 AS Gold Plating Solution   General Information NB Semiplate AU 100 AS is an alkaline, non-cyanide electroplating formulation based on arsenic grain refiner which produces a bright, ductile deposit. In comparison with other gold plating processes, the NB Semiplate AU 100 AS electrolyte demonstrates exceptional throwing power that results in good coverage of recesses, holes and hollows of parts of complex geometry. Deposits from the NB Semiplate AU 100 process also exhibit the unique ability to build brightness with increasing thickness. NB Semiplate AU 100 AS deposits have main applications in MEMS processing. NB Semiplate AU 100 NOTE: NB Semiplate AU 100 AS is a ready-to-use product. It is not necessary to add other materials for the initially start of the application. Over time, it may be necessary depending on the electrolyte and application to add additives (see data sheet). With adjusted photoresist processing, the NB Semiplate AU 100 AS is compatible with common AZ®- and TI resists. Product Properties Purity: 99.9% Hardness: approx. 130 to 190 HV0,020 Contact Resistance: 0.3 mW (measured by cross-wire method with 200 gram load.) Deposit weight for 2.5 microns: 31.6 mg/in2 (4.9 mg/cm2)(100 µin) Further Information MSDS: Safety Data Sheet NB Semiplate AU 100 AS english Sicherheitsdatenblatt NB Semiplate AU 100 AS german TDS: Technical Data Sheet NB Semiplate AU 100 AS english Application Notes: Instruction NBT Sample Service for Plating Baths english Anleitung NBT Probenservice für Galvanikbäder german Plating Theory english Galvanik Theorie german Plating and Photoresist english Galvanik und Fotolacke german Further Information about Processing

NB Semiplate AU 100 TL Gold Plating Solution without arsenic   General Information NB Semiplate AU 100 TL is an alkaline, non-cyanide electroplating formulation which produces a matte to semi-bright, ductile deposit. While the NB Semiplate AU 100 AS product contains arsenic for achieving shiny deposits, the NB Semiplate AU 100 TL is based on thallium and free of arsenic. In comparison with other gold plating processes, the NB Semiplate AU 100 TL electrolyte demonstrates exceptional throwing power that results in good coverage of recesses, holes and hollows of parts of complex geometry. NB Semiplate AU 100 TL deposits have main applications in MEMS processing. Product: Brightening agent: Surface / grain: NB Semiplate AU 100 TL thallium matt to semi-bright / coarse NB Semiplate AU 100 AS arsenic shiny / fine   NB Semiplate AU 100 NOTE: NB Semiplate AU 100 TL is a ready-to-use product. It is not necessary to add other materials for the initially start of the application. Over time, it may be necessary depending on the electrolyte and application to add additives (see data sheet). With adjusted photoresist processing, the NB Semiplate AU 100 TL is compatible with common AZ®- and TI resists. Product Properties Purity: 99.9% Hardness: approx. 130 to 190 HV0,020 Contact Resistance: 0.3 mW (measured by cross-wire method with 200 gram load.) Deposit weight for 2.5 microns: 31.6 mg/in2 (4.9 mg/cm2) (100 µin) Further Information MSDS: Safety Data Sheet NB Semiplate AU 100 TL english Sicherheitsdatenblatt NB Semiplate AU 100 TL german TDS: Technical Data Sheet NB Semiplate AU 100 TL english Application Notes: Instruction NBT Sample Service for Plating Baths english Anleitung NBT Probenservice für Galvanikbäder german Plating Theory english Galvanik Theorie german Plating and Photoresist english Galvanik und Fotolacke german Further Information about Processing

NB Semiplate CU 100 Copper Plating Solution   General Information The NB Semiplate CU 100 process is an acid copper plating formulation engineered for wafer plating applications including copper bump plating, interconnects for VLSI/ULSI or MEMS. The NB Semiplate CU 100 process provides excellent throwing power, improved leveling characteristics, ductile low stress deposits and offers unique flexibility in its operation. NB Semiplate CU 100 NOTE: NB Semiplate CU 100 is a ready-to-use product. It is not necessary to add other materials for the initially start of the application. Over time, it may be necessary depending on the electrolyte and application to add additives (see data sheet). With adjusted photoresist processing, the NB Semiplate CU 100 is compatible with common AZ®- and TI resists. Further Information MSDS: Safety Data Sheet NB Semiplate CU 100 english Sicherheitsdatenblatt NB Semiplate CU 100 german TDS: Technical Data Sheet NB Semiplate CU 100 english Application Notes: Instruction NBT Sample Service for Plating Baths english Anleitung NBT Probenservice für Galvanikbäder german Plating Theory english Galvanik Theorie german Plating and Photoresist english Galvanik und Fotolacke german Further Information about Processing

NB Semiplate CU 150 Copper Plating Solution   General Information The NB Semiplate CU 150 process is an acid copper plating formulation engineered for wafer plating applications including copper bump plating, interconnects or MEMS. The NB Semiplate CU 150 process provides excellent throwing power, improved levelling characteristics, ductile low stress deposits and offers unique flexibility in its operation. This product is specially designed for the operation with inert anode systems without negative impact on plating quality or sensitive compounds such as organic additives. However, the operation using soluble anodes is not excluded. NB Semiplate CU 150 NOTE: NB Semiplate CU 150 is a ready-to-use product. It is not necessary to add other materials for the initially start of the application. Over time, it may be necessary depending on the electrolyte and application to add additives (see data sheet). With adjusted photoresist processing, the NB Semiplate CU 150 is compatible with common AZ®- and TI resists. Further Information MSDS: Safety Data Sheet NB Semiplate CU 150 english Sicherheitsdatenblatt NB Semiplate CU 150 german TDS: Technical Data Sheet NB Semiplate CU 150 english Application Notes: Instruction NBT Sample Service for Plating Baths english Anleitung NBT Probenservice für Galvanikbäder german Plating Theory english Galvanik Theorie german Plating and Photoresist english Galvanik und Fotolacke german Further Information about Processing

NB Semiplate IN 100 Indium Plating Solution   General Information The NB Semiplate IN 100 process is an alkaline, non-cyanide indium plating formulation. Deposits obtained from the NB Semiplate IN 100 bath are matte and fine-grained. Throwing power is excellent. The alkaline nature of the bath eliminates the impurity build-up of nickel, iron and copper. NB Semiplate IN 100 deposits have main applications in semiconductor or MEMS processing for bonding purposes, however, standard photo resist products are not applicable/compatible for patterned depositions. NOTE: NB Semiplate IN 100 is a ready-to-use product. It is not necessary to add other materials for the initially start of the application. Over time, it may be necessary depending on the electrolyte and application to add additives (see data sheet). With adjusted photoresist processing, the NB Semiplate IN 100 is compatible with common AZ®- and TI resists. Product Properties Purity: 99% Specific gravity (g/cm3): 7.0 For 1 micron deposit (mg/dm2): 70 Further Information MSDS: Safety Data Sheet NB Semiplate IN 100 english Sicherheitsdatenblatt NB Semiplate IN 100 german TDS: Technical Data Sheet NB Semiplate IN 100 english Application Notes: Instruction NBT Sample Service for Plating Baths english Anleitung NBT Probenservice für Galvanikbäder german Plating Theory english Galvanik Theorie german Plating and Photoresist english Galvanik und Fotolacke german Further Information about Processing

NB Semiplate PD 200 Palladium Plating Solution   General Information NB Semiplate PD 200 is a neutral/weak alkaline electroplating formulation which produces a shiny deposit up to 1.5 µm thickness. The deposits show good adhesion and low stress. NB Semiplate PD 200 deposits have main applications in MEMS processing. NOTE: NB Semiplate PD 200 is a ready-to-use product. It is not necessary to add other materials for the initially start of the application. Over time, it may be necessary depending on the electrolyte and application to add additives (see data sheet). Further Information MSDS: Safety Data Sheet NB Semiplate PD 200 english Sicherheitsdatenblatt NB Semiplate PD 200 german TDS: Technical Data Sheet NB Semiplate PD 200 english Application Notes: Instruction NBT Sample Service for Plating Baths english Anleitung NBT Probenservice für Galvanikbäder german Plating Theory english Galvanik Theorie german Plating and Photoresist english Galvanik und Fotolacke german Further Information about Processing

NB Semiplate SN 100 Tin Plating Solution   General Information NB Semiplate SN 100 is a high-purity electroplating process which produces fine-grained, matte, pure tin deposits. It is especially formulated for use in the fabrication of circuit patterns and bumps on semiconductor wafers. The process contains no fluoborates or formaldehyde and is operated with soluble anodes. NOTE: NB Semiplate SN 100 is a ready-to-use product. It is not necessary to add other materials for the initially start of the application. Over time, it may be necessary depending on the electrolyte and application to add additives (see data sheet). With adjusted photoresist processing, the NB Semiplate SN 100 is compatible with common AZ®- and TI resists. Further Information MSDS: Safety Data Sheet NB Semiplate SN 100 english Sicherheitsdatenblatt NB Semiplate SN 100 german TDS: Technical Data Sheet NB Semiplate SN 100 english Application Notes: Instruction NBT Sample Service for Plating Baths english Anleitung NBT Probenservice für Galvanikbäder german Plating Theory english Galvanik Theorie german Plating and Photoresist english Galvanik und Fotolacke german Further Information about Processing
