Photoresist

AZ® 10XT (220CPS) Thick photoresist for high resolution   General Information AZ® 10XT is an i- and h-line (not g- line !) sensitive positive thick photoresist, as the successor to the AZ® 9260 and is largely identical in construction, but with a different surfactant. In contrast to the similarly named AZ® 12XT, the AZ® 10XT is not chemically amplified.   3.0 µm lines in 12 µm thick AZ® 10XT Ultratech 1500 Exposure, AZ® 400K Developer 1:4 (260s spray)   Product Features AZ® 10XT not only has optimized resist adhesion to common substrate materials, but also the potential for very steep resist sidewalls and high aspect ratios. Accordingly, the AZ® 10XT is often used in electroplating, ion implantation or dry etching/RIE. AZ® 10XT achieves a resist film thickness of approx. 6 µm at a spin speed of 4000 rpm; with an appropriately adjusted spin profile, the resist film thickness range of approx. 4.5 - 20 µm can be covered. If thinner resist layers are desired, the AZ® 10XT can be diluted with PGMEA; alternatively, the thinner AZ® 4533 can also be used for many applications. From a resist film thickness of approximately 10 - 15 µm, processing the AZ® 10XT becomes increasingly time-consuming: the soft bake and subsequent development take longer, more and more time is needed for rehydration between soft bake and exposure, and the risk of nitrogen bubbles forming during exposure increases. For resist film thicknesses greater than 10 µm, it is recommended to consider using a chemically amplified thick resist such as AZ® 12 XT (5 - 20 µm resist film thickness) or AZ®IPS 6090 (> 20 µm resist film thickness), which have significantly shorter soft bake and development times for the corresponding resist thickness, do not need rehydration, require significantly lower exposure doses, and do not release nitrogen during exposure. Developers For development, we recommend either TMAH-based developers such as the ready-to-use AZ® 326 MIF or AZ® 726 MIF, or the KOH-based AZ® 400K 1:4 (typically 1: 4 diluted with water, for faster development also slightly stronger with 1:3.5 or 1:3). On alkaline-sensitive substrate materials such as aluminum, we recommend the aluminum-compatible, undiluted AZ® Developer. Removers If the resist structures have not been thermally cross-linked by plasma processes, ion implantation or high temperatures (> approx. 140 °C), all common removers such as AZ® 100 Remover, DMSO or many other organic solvents (e.g. Acetone rinsed with Isopropanol) are suitable for removing the resist layer. For cross-linked resist structures, high-performance strippers such as the NMP-free TechniStrip P1316 or AZ® 920 Remover are recommended, and in the case of alkaline-sensitive substrate materials (such as aluminum), the TechniStrip MLO 07. Thinning / Edge Wall Removal If the resist is to be diluted for spin coating, PGMEA = AZ® EBR Solvent is the recommended solvent. PGMEA is the solvent for AZ® 10 XT anyway and is also recommended for edge wall removal if necessary. Further Information Our safety data sheets and some of our technical data sheets are password-protected. You will receive the access data after completing the form. The access data for the data sheets are not your login data from our shop! MSDS: Safety Data Sheet AZ® 10XT (220cps) english Safety Data Sheet AZ® 10XT (220cps) german TDS: Technical Data Sheet AZ® 10XT (220cps) english Application Notes: Further Information about Photoresist Processing

AZ® 10XT (520CPS) Thick photoresist for high resolution   General Information AZ® 10XT is an i- and h-line (not g- line !) sensitive positive thick photoresist, as the successor to the AZ® 9260 and is largely identical in construction, but with a different surfactant. In contrast to the similarly named AZ® 12XT, the AZ® 10XT is not chemically amplified.   3.0 µm lines in 12 µm thick AZ® 10XT Ultratech 1500 Exposure, AZ® 400K Developer 1:4 (260s spray)   Product Features AZ® 10XT not only has optimized resist adhesion to common substrate materials, but also the potential for very steep resist sidewalls and high aspect ratios. Accordingly, the AZ® 10XT is often used in electroplating, ion implantation or dry etching/RIE. AZ® 10XT achieves a resist film thickness of approx. 6 µm at a spin speed of 4000 rpm; with an appropriately adjusted spin profile, the resist film thickness range of approx. 4.5 - 20 µm can be covered. If thinner resist layers are desired, the AZ® 10XT can be diluted with PGMEA; alternatively, the thinner AZ® 4533 can also be used for many applications. From a resist film thickness of approximately 10 - 15 µm, processing the AZ® 10XT becomes increasingly time-consuming: the soft bake and subsequent development take longer, more and more time is needed for rehydration between soft bake and exposure, and the risk of nitrogen bubbles forming during exposure increases. For resist film thicknesses greater than 10 µm, it is recommended to consider using a chemically amplified thick resist such as AZ® 12 XT (5 - 20 µm resist film thickness) or AZ®IPS 6090 (> 20 µm resist film thickness), which have significantly shorter soft bake and development times for the corresponding resist thickness, do not need rehydration, require significantly lower exposure doses, and do not release nitrogen during exposure. Developers For development, we recommend either TMAH-based developers such as the ready-to-use AZ® 326 MIF or AZ® 726 MIF, or the KOH-based AZ® 400K 1:4 (typically 1: 4 diluted with water, for faster development also slightly stronger with 1:3.5 or 1:3). On alkaline-sensitive substrate materials such as aluminum, we recommend the aluminum-compatible, undiluted AZ® Developer. Removers If the resist structures have not been thermally cross-linked by plasma processes, ion implantation or high temperatures (> approx. 140 °C), all common removers such as AZ® 100 Remover, DMSO or many other organic solvents (e.g. Acetone rinsed with Isopropanol) are suitable for removing the resist layer. For cross-linked resist structures, high-performance strippers such as the NMP-free TechniStrip P1316 or AZ® 920 Remover are recommended, and in the case of alkaline-sensitive substrate materials (such as aluminum), the TechniStrip MLO 07. Thinning / Edge Wall Removal If the resist is to be diluted for spin coating, PGMEA = AZ® EBR Solvent is the recommended solvent. PGMEA is the solvent for AZ® 10 XT anyway and is also recommended for edge wall removal if necessary.     Further Information Our safety data sheets and some of our technical data sheets are password-protected. You will receive the access data after completing the form. The access data for the data sheets are not your login data from our shop! MSDS: Safety Data Sheet AZ® 10XT (520cps) english Safety Data Sheet AZ® 10XT (520cps) german TDS: Technical Data Sheet AZ® 10XT (520cps) english Anwendungshinweis: Further Information about Photoresist Processing

AZ® 125nXT-10B Ultra-Thick Negative Resist for Plating   General Information The AZ® 125nXT-10B is an i-line sensitive, negative ultra-thick resist with steep resist sidewalls and high aspect ratio. 20 µm lines at 60 µm resist film thickness. 15 µm holes at 60 µm resist film thickness. 80 µm plated CuNi image. Product Features The ultra-thick negative resist AZ® 125nXT-10B covers a resist film thickness range of 20 - 50 µm and can be built up and processed to 100 µm and much more with adapted spin profiles. AZ® 125nXT-10B is only i-line sensitive and, as a special feature (for negative resists), does not require a post exposure bake after exposure for cross-linking, i.e. the AZ® 125nXT-10B photopolymerizes. Due to its low absorption, even very thick resist layers can be easily exposed and steep resist sidewalls can be achieved. This and its very good adhesion to all common substrate materials make this resist suitable for the galvanic molding of thick to very thick layers as well as DRIE. With low exposure doses or very thick resist layers - related to the respective resist film thickness - the resist profile becomes slightly negative, since the resist areas close to the substrate experience less cross-linking. If the electroplating process shows that these weakly cross-linked areas of the resist are attacked, but a higher structuring exposure dose is not an option, flood exposure (without a photomask) after development with very high doses can cross-link the resist sidewalls even near the substrate, which, however, makes it more difficult to strip the resist later. Even after such flood exposure, no further post exposure back is necessary. AZ® 125nXT-10B can generally be processed with resist films of less than 20 µm thick, but processing becomes problematic below 10 µm thickness: Since the additive responsible for cross-linking escapes from the resist surface during softbaking, only a few micrometers of the exposed resist surface are removed during development, which accounts for a correspondingly large proportion of the total thickness in the case of thin resist films. Developers AZ® 326 MIF (immersion development), AZ® 726 MIF (puddle development) or AZ® 2026 MIF (which has an additive that promotes residue-free development, especially with cross-linking resists) are recommended for developing the AZ® 125nXT-10B. KOH- or NaOH-based developers such as AZ® 400K or AZ® 351B are generally not suitable for the AZ® 125nXT-10B. If TMAH-based developers cannot be used, a KOH-based developer in higher concentration than usual can be considered. Removers AZ® 125nXT-10B can be removed wet-chemically using conventional strippers, but stripping very thick cross-linked resist structures can be quite a challenge. If organic solvents are preferred for this, (hot) DMSO is recommended, which does not dissolve cross-linked resists, but can detach them from the substrate after a certain exposure time. This process can be accelerated by reducing the degree of cross-linking of the resist near the substrate by using a lower exposure dose. Alternatively, high-performance strippers such as the NMP-free TechniStrip P1316 are recommended, or in the case of alkaline-sensitive substrate materials (such as aluminum), the TechniStrip MLO 07. Thinning/ Edge Wall Removal If the resist is to be diluted for spin coating, PGMEA = AZ® EBR Solvent is an option. PGMEA is the solvent for AZ® 125nXT-10B anyway and is also recommended for edge wall removal if necessary.     Further Information Our safety data sheets and some of our technical data sheets are password-protected. You will receive the access data after completing the form. The access data for the data sheets are not your login data from our shop! MSDS: Safety Data Sheet AZ® 125nXT-10B english Safety Data Sheet AZ® 125nXT-10B german TDS: Technical Data Sheet AZ® 125nXT-10B english Application Notes: Further Information about Photoresist Processing

AZ® 12XT-20PL-10 Chemically Amplified Positive Tone Photoresists   General Information AZ® 12XT is a chemically amplified, i-line sensitive thick photoresist for high aspect ratios and with an increased thermal softening point.   AZ® 12XT - 2.4mm lines at 10mm film thickness   Product Features AZ® 12XT covers a resist film thickness range of approx. 5 - 20 µm. As a chemically amplified resist, the AZ® 12XT does not require rehydration between softbake and exposure, requires significantly lower exposure doses compared to non-chemically amplified resists of comparable thickness, does not release nitrogen during exposure (no bubble formation in the resist film during exposure), and has very high development rates for a thick resist. These properties help to make the entire process significantly faster and less prone to problems than with non-chemically amplified thick resists. Its good adhesion to all common substrate materials and its potential for steep resist sidewalls make it suitable for galvanic molding, and its high thermal softening point (approx. 130 °C) also recommends it for dry etching or DRIE. Basically, the AZ® 12XT is only sensitive to i-line, but with correspondingly high exposure doses and resist film thicknesses, the h-line (405 nm) can also be used. If resist film thicknesses of less than approx. 5 µm are required, the AZ® 12XT can easily be diluted with PGMEA = AZ® EBR Solvent. For resist film thicknesses greater than 15 µm, the chemically amplified AZ® IPS 6090 should be considered. Developers TMAH-based developers such as the ready-to-use AZ® 326 MIF or AZ® 726 MIF are recommended for developing this chemically amplified photoresist. KOH- or NaOH-based developers such as the AZ® 400 K or AZ® 351B are less suitable for the AZ® 12 XT. Removers If the resist structures have not been thermally cross-linked by plasma processes, ion implantation or high temperatures (> approx. 140 °C), all common removers such as AZ® 100 Remover, DMSO or many other organic solvents (e.g. acetone rinsed with isopropanol) are suitable for removing the resist layer. For cross-linked resist structures, high-performance strippers such as the NMP-free TechniStrip P1316 or AZ® 920 Remover are recommended, and in the case of alkaline-sensitive substrate materials (such as aluminum), the TechniStrip MLO 07. Thinning/ Edge Bead Removal If the resist is to be diluted for spin coating, PGMEA = AZ® EBR Solvent is an option. PGMEA is the solvent for AZ® 12 XT anyway and is also recommended for edge wall removal if necessary.     Further Information Our safety data sheets and some of our technical data sheets are password-protected. You will receive the access data after completing the form. The access data for the data sheets are not your login data from our shop! MSDS: Safety Data Sheet AZ® 12XT 20PL-10 english Safety Data Sheet AZ® 12XT 20PL-10 german TDS: Technical Data Sheet AZ® 12XT 20PL-10 english Application Notes: Further Information about Photoresist Processing

AZ® 12XT-20PL-15 Chemically Amplified Positive Tone Photoresists   General Information AZ® 12XT is a chemically amplified, i-line sensitive thick photoresist for high aspect ratios and with an increased thermal softening point.   AZ® 12XT - 2.4mm lines at 10mm film thickness   Product Features AZ® 12XT covers a resist film thickness range of approx. 5 - 20 µm. As a chemically amplified resist, the AZ® 12XT does not require rehydration between softbake and exposure, requires significantly lower exposure doses compared to non-chemically amplified resists of comparable thickness, does not release nitrogen during exposure (no bubble formation in the resist film during exposure), and has very high development rates for a thick resist. These properties help to make the entire process significantly faster and less prone to problems than with non-chemically amplified thick resists. Its good adhesion to all common substrate materials and its potential for steep resist sidewalls make it suitable for galvanic molding, and its high thermal softening point (approx. 130 °C) also recommends it for dry etching or DRIE. Basically, the AZ® 12XT is only sensitive to i-line, but with correspondingly high exposure doses and resist film thicknesses, the h-line (405 nm) can also be used. If resist film thicknesses of less than approx. 5 µm are required, the AZ® 12XT can easily be diluted with PGMEA = AZ® EBR Solvent. For resist film thicknesses greater than 15 µm, the chemically amplified AZ® IPS 6090 should be considered. Developers TMAH-based developers such as the ready-to-use AZ® 326 MIF or AZ® 726 MIF are recommended for developing this chemically amplified photoresist. KOH- or NaOH-based developers such as the AZ® 400 K or AZ® 351B are less suitable for the AZ® 12 XT. Removers If the resist structures have not been thermally cross-linked by plasma processes, ion implantation or high temperatures (> approx. 140 °C), all common removers such as AZ® 100 Remover, DMSO or many other organic solvents (e.g. acetone rinsed with isopropanol) are suitable for removing the resist layer. For cross-linked resist structures, high-performance strippers such as the NMP-free TechniStrip P1316 or AZ® 920 Remover are recommended, and in the case of alkaline-sensitive substrate materials (such as aluminum), the TechniStrip MLO 07. Thinning/ Edge Wall Removal If the resist is to be diluted for spin coating, PGMEA = AZ® EBR Solvent is an option. PGMEA is the solvent for AZ® 12 XT anyway and is also recommended for edge wall removal if necessary.     Further Information Our safety data sheets and some of our technical data sheets are password-protected. You will receive the access data after completing the form. The access data for the data sheets are not your login data from our shop! MSDS: Safety Data Sheet AZ® 12XT 20PL-15 english Safety Data Sheet AZ® 12XT 20PL-15 german TDS: Technical Data Sheet AZ® 12XT 20PL-15 english Application Notes: Further Information about Photoresist Processing

AZ® 1505 Positive Thin Resists for Wet Etching   General Information The AZ® 1505 Photoresist belongs to the AZ® 1500 Photoresist Series of positive thin resists (g-, h- and i-line sensitive) with optimized adhesion to all common substrate materials, the main application of which is as a resist mask for wet etching. Product Properties AZ® 1500 Resist Family is not optimized for very steep resist sidewalls nor for high stability against thermal softening (softening temperature approx. 100 °C), but for improved adhesion to all common substrate materials. The high photoinitiator concentration of the AZ® 1500 Photoresist Series compared to thick resists allows for very fast development. AZ® 1505 Photoresist is the thinnest member of the AZ® 1500 Photoresist Series with a resist film thickness of approx. 500 nm at 4000 rpm. This resist is often used for chrome etching in photomask production, but is also suitable as an etching mask for other materials. AZ® 1505 allows a resolution in the submicrometer range under optimized process parameters. If such a high resolution is not required, a slightly thicker resist (for example AZ® 1514 H Photoresist or AZ® 1518 Photoresist) can be useful, which reduces the risk of pinholes in the resist film caused by particles on the substrate and the corresponding etching defects. Further dilution of the AZ® 1505 is not recommended, as heavily diluted, photoinitiator-rich resists tend to quickly form particles. If the resist does have to be diluted, the corresponding batches should be used up quickly and attention should be paid to possible particle formation. Developers For development, we recommend either TMAH-based developers such as AZ® 326 MIF or AZ® 726 MIF, the NaOH-based AZ® 351B, and if the requirements for selectivity are not too high, the KOH-based AZ® 400K. With AZ® 351Bor AZ® 400K, it may be advisable to work with a higher diluted developer (for example 1:5 to 1:6) instead of the usual 1:4 dilution to achieve very fine resist structures or better controllable development times. On alkaline-sensitive substrate materials such as aluminum, we recommend the aluminum-compatible AZ® Developer in a 1:1 dilution. Removers If the resist structures have not been thermally cross-linked by plasma processes, ion implantation or high temperatures (> approx. 140°C), all common removers such as AZ® 100 Remover, DMSO or many other organic solvents (e.g. acetone rinsed with isopropyl alcohol) are suitable for removing the resist layer. For cross-linked resist structures, high-performance strippers such as the NMP-free TechniStrip P1316 or AZ® 920 Remover are recommended, and in the case of alkaline-sensitive substrate materials (such as aluminum), the TechniStrip MLO 07. Thinning/ Edge Bead Removal Even if, as described above, further dilution of AZ® 1505 Photoresist is not recommended due to the accelerated particle formation, PGMEA = AZ® EBR Solvent is the recommended solvent. PGMEA is the solvent for AZ® 1505 anyway and is also recommended for edge wall removal if necessary.     Further Information Our safety data sheets and some of our technical data sheets are password-protected. You will receive the access data after completing the form. The access data for the data sheets are not your login data from our shop! MSDS: Safety Data Sheet AZ® 1505 Photoresist english Safety Data Sheet AZ® 1505 Photoresist german TDS: Technical Data Sheet AZ® 1505 Photoresist english Application Notes: Further Information about Photoresist Processing

AZ® 1512 HS Positive Thin Resists for Wet Etching   General Information The AZ® 1512 HS Photoresist belongs to the AZ® 1500 Photoresist Series of positive thin resists (g-, h- and i-line sensitive) with optimized adhesion to all common substrate materials, the main application of which is as a resist mask for wet etching. Product Properties AZ® 1500 Resist Family is not optimized for very steep resist sidewalls nor for high stability against thermal softening (softening temperature approx. 100°C), but for improved adhesion to all common substrate materials. The high photoinitiator concentration of the AZ® 1500 Photoresist Series compared to thick resists allows for very fast development. AZ® 1512 HS Photoresist achieves a resist film thickness of approx. 1.3 µm at 4000 rpm and is often used for chrome etching in photomask production, but is also suitable as an etching mask for other materials. AZ® 1512 HS allows a resolution in the submicrometer range under optimized process parameters. If such a high resolution is not required, a slightly thicker resist (for example AZ® 1518 Photoresist) can be useful, which reduces the risk of pinholes in the resist layer caused by particles on the substrate and the corresponding etching defects. AZ® 1512 HS Photoresist has the highest photoinitiator concentration within the AZ® 1500 Photoresist Series, is correspondingly high in contrast, and shows a particularly high development rate. Diluting the AZ® 1512 HS is not advisable, as diluted resists that are very rich in photoinitiators tend to quickly form particles. If the resist still needs to be diluted, the corresponding amounts should be used up quickly and attention should be paid to possible particle formation. Developers For development, we recommend either TMAH-based developers such as AZ® 326 MIF or AZ® 726 MIF, the NaOH-based AZ® 351B (typically 1:4 diluted with water), and if the selectivity requirements are not too high, the KOH-based AZ® 400K (also typically 1:4 diluted with water). For very fine resist structures, a slightly higher dilution of the developer can be helpful. On alkaline-sensitive substrate materials such as aluminum, we recommend the aluminum-compatible AZ® Developer in a 2:1 to 1:1 dilution (developer : water). Removers If the resist structures have not been thermally cross-linked by plasma processes, ion implantation or high temperatures (> approx. 140°C), all common removers such as AZ® 100 Remover, DMSO or many other organic solvents (e.g. acetone rinsed with isopropyl alcohol) are suitable for removing the resist layer. For cross-linked resist structures, high-performance strippers such as the NMP-free TechniStrip P1316 or AZ® 920 Remover are recommended, and in the case of alkaline-sensitive substrate materials (such as aluminum), the TechniStrip MLO 07. Thinning/ Edge Bead Removal Even if, as described above, further dilution of AZ® 1515 HS Photoresistis not recommended due to the accelerated particle formation, PGMEA = AZ® EBR Solvent is the recommended solvent. PGMEA is the solvent for AZ® 1512 HS anyway and is also recommended for edge wall removal if necessary.     Further Information Our safety data sheets and some of our technical data sheets are password-protected. You will receive the access data after completing the form. The access data for the data sheets are not your login data from our shop! MSDS: Safety Data Sheet AZ® 1512 HS Photoresist english Safety Data Sheet AZ® 1512 HS Photoresist german TDS: Technical Data Sheet AZ® 1512 HS Photoresist english Application Notes: Further Information about Photoresist Processing

AZ® 1514 H Positive Thin Resist for Wet Etching   General Information The AZ® 1514 H Photoresist belongs to the AZ® 1500 Photoresist Series of positive thin resists (g-, h- and i-line sensitive) with optimized adhesion to all common substrate materials, the main application of which is as a resist mask for wet etching. Product Properties AZ® 1500 Resist Family is not optimized for very steep resist sidewalls nor for high stability against thermal softening (softening temperature approx. 100°C), but for improved adhesion to all common substrate materials. The high photoinitiator concentration of the AZ® 1500 Photoresist Series compared to thick resists allows for very fast development. AZ® 1514 H Photoresist achieves a resist film thickness of approx. 1.5 µm at 4000 rpm and has particularly good adhesion to metallic substrate materials, making it suitable as an etching mask for aluminum, chrome and other metals, for example, but also for etching non-metallic layers. It is not advisable to dilute the AZ® 1514 H Photoresist too much, as diluted, photoinitiator-rich resists tend to quickly form particles. If the resist does need to be diluted, the corresponding amounts should be used up quickly and attention should be paid to possible particle formation. Developers For development, we recommend either TMAH-based developers such as the ready-to-use AZ® 326 MIF or AZ® 726 MIF, the NaOH-based AZ® 351B (typically 1:4 diluted with water), and if the selectivity requirements are not too high, the KOH-based AZ® 400K (also typically 1:4 diluted with water). For very fine resist structures, a slightly higher dilution of the developer can be helpful. On alkaline-sensitive substrate materials such as aluminum, we recommend the aluminum-compatible AZ® Developer in a 2:1 to 1:1 dilution (developer : water). Removers If the resist structures have not been thermally cross-linked by plasma processes, ion implantation or high temperatures (> approx. 140°C), all common removers such as AZ® 100 Remover, DMSO or many other organic solvents (e.g. acetone rinsed with isopropyl alcohol) are suitable for removing the resist layer. For cross-linked resist structures, high-performance strippers such as the NMP-free TechniStrip P1316 or AZ® 920 Remover are recommended, and in the case of alkaline-sensitive substrate materials (such as aluminum), the TechniStrip MLO 07. Thinning/ Edge Bead Removal Even if, as described above, further dilution of AZ® 1514 H Photoresist is not recommended due to the accelerated particle formation, PGMEA = AZ® EBR Solvent is the recommended solvent. PGMEA is the solvent for AZ® 1514 H anyway and is also recommended for edge wall removal if necessary.     Further Information Our safety data sheets and some of our technical data sheets are password-protected. You will receive the access data after completing the form. The access data for the data sheets are not your login data from our shop! MSDS: Safety Data Sheet AZ® 1514 H Photoresist english Safety Data Sheet AZ® 1514 H Photoresist german TDS: Technical Data Sheet AZ® 1514 H Photoresist english Application Notes: Further Information about Photoresist Processing

AZ® 1518 Positive Thin Resist for Wet Etching   General Information AZ® 1518 belongs to the AZ® 1500 photoresist series of positive thin resists (g-, h- and i-line sensitive) with optimized adhesion to all common substrate materials, the main application of which is as a resist mask for wet etching. Product Properties AZ® 1500 resist family is not optimized for very steep resist sidewalls nor for high stability against thermal softening (softening temperature approx. 100 °C), but for improved adhesion to all common substrate materials. The high photoinitiator concentration of the AZ® 1500 series compared to thick resists allows for very fast development. AZ® 1518 achieves a resist film thickness of approx. 1.8 µm at 4000 rpm and is often used for etching metallic or non-metallic layers. It is not advisable to dilute the AZ® 1518 below the level of the AZ® 1505, as diluted, photoinitiator-rich resists tend to quickly form particles. If the resist does have to be diluted, the corresponding amounts should be used up quickly and attention should be paid to possible particle formation. AZ® 1518 should not be processed with a resist film thickness significantly thicker than approx. 2 µm, as the high photoinitiator concentration can lead to the formation of nitrogen bubbles in the resist film when exposed to light as the resist thickness increases. If thicker resist films are required, the AZ® 4533, which has a significantly lower photoinitiator content, is recommended. Developers For development, we recommend either TMAH-based developers such as the ready-to-use AZ® 326 MIF or AZ® 726 MIF, the NaOH-based AZ® 351B (typically 1: 4 diluted with water), and if the selectivity requirements are not too high, the KOH-based AZ® 400K K (also typically 1:4 diluted with water). On alkaline-sensitive substrate materials such as aluminum, we recommend the aluminum-compatible AZ® Developer in a 2: 1 to 1:1 dilution (developer:water). Removers If the resist structures have not been thermally cross-linked by plasma processes, ion implantation or high temperatures (> approx. 140 °C), all common removers such as AZ® 100 Remover, DMSO or many other organic solvents (e.g. acetone rinsed with isopropanol) are suitable for removing the resist layer. For cross-linked resist structures, high-performance strippers such as the NMP-free TechniStrip P1316 or AZ® 920 Remover are recommended, and in the case of alkaline-sensitive substrate materials (such as aluminum), the TechniStrip MLO 07. Thinning/ Edge Bead Removal Even if, as described above, a stronger dilution of AZ® 1518 is not recommended due to the accelerated particle formation, PGMEA = AZ® EBR Solvent.is the recommended solvent. PGMEA is the solvent for AZ® 1518 anyway and is also recommended for edge wall removal if necessary.     Further Information Our safety data sheets and some of our technical data sheets are password-protected. You will receive the access data after completing the form. The access data for the data sheets are not your login data from our shop! MSDS: Safety Data Sheet AZ® 1518 Photoresist english Safety Data Sheet AZ® 1518 Photoresist german TDS: Technical Data Sheet AZ® 1518 Photoresist english Application Notes: Further Information about Photoresist Processing)

AZ® 15nXT (115CPS) Thick Negative Resist for Plating   General Information The i-line sensitive negative resist AZ® 15nXT (115CPS) is a thick resist with approx. 3 - 5 µm film thickness and very steep resist sidewalls for e. g. RIE or electroplating, for example. 5 µm lines at 10 µm resist film thickness. 5 µm holes at 10 µm resist film thickness. 5 µm plated CuNi image. 3.6 µm plated CuNi image. Product Features AZ® 15nXT (115CPS) covers a resist film thickness range of - depending on the spin speed - approx. 2 - 3 µm. It is only i-line sensitive and requires a post exposure bake after exposure to complete the cross-linking induced during exposure. The resist structures developed are very vertical with adjusted process parameters, becoming increasingly negative towards thick resist films or - based on the respective resist film thickness - lower exposure doses. If thinner resist films are required, the AZ® 15nXT (115CPS) can be diluted with PGMEA = AZ® EBR Solvent; for thicker layers, the higher viscosity AZ® 15nXT (450CPS) is recommended. AZ® 15nXT (115CPS) is suitable as a mask for the galvanic deposition of e.g. Cu, Ni or Au due to its good adhesion to all common substrate materials and its high chemical stability. Developers For the development of the AZ® 15nXT (115CPS), TMAH-based developers such as the ready-to-use AZ® 326 MIF (immersion development), AZ® 726 MIF (puddle development) or AZ® 2026 MIF are recommended, which promotes residue-free development, especially with cross-linking resists, thanks to an additive. KOH- or NaOH-based developers such as the AZ® 400 K or AZ® 351B are generally not suitable for the AZ® 15nXT (115CPS). If TMAH-based developers cannot be used, an attempt with a KOH-based developer in higher concentration than usual can be considered. Removers If the resist structures have not been thermally cross-linked too much, for example through metallization, stripping or lift-off with organic solvents (acetone rinsed with isopropanol or DMSO) can be successful. For more strongly cross-linked resist structures, high-performance strippers such as the NMP-free TechniStrip NI555 or AZ® 910 Remover are recommended, or in the case of alkaline-sensitive substrate materials (such as aluminum), the TechniStrip MLO 07. Thinning/ Edge Wall Removal If the resist is to be diluted for spin coating, PGMEA = AZ® EBR Solvent is an option. PGMEA is the solvent for AZ® 15nXT (115CPS) anyway and is also recommended for edge wall removal if necessary.     Further Information Our safety data sheets and some of our technical data sheets are password-protected. You will receive the access data after completing the form. The access data for the data sheets are not your login data from our shop! MSDS: Safety Data Sheet AZ® 15nXT (115CPS) Photoresist english Safety Data Sheet AZ® 15nXT (115CPS) Photoresist german TDS: Technical Data Sheet AZ® 15nXT (115CPS) Photoresist english Technical Data Sheet AZ® 15nXT Series english Application Notes: Further Information about Photoresist Processing

AZ® 15nXT (450CPS) Thick Negative Resist for Plating   General Information The i-line sensitive negative resist AZ® 15nXT (450CPS) is a thick resist with a thickness of approx. 5 - 10 µm and vertical resist sidewalls for RIE or electroplating, for example. 5 µm lines at 10 µm resist film thickness. 5 µm holes at 10 µm resist film thickness. 5 µm plated CuNi image. 3.6 µm plated CuNi image. Product Features AZ® 15nXT (450CPS) covers a resist film thickness range of - depending on the spin speed - approx. 5 - 10 µm. It is only i-line sensitive and requires a post exposure bake after exposure to complete the cross-linking induced during exposure. With adjusted process parameters, the resist structures developed are vertical, increasingly negative towards thick resist films or - based on the respective resist film thickness - lower exposure doses. If thinner resist films are required, the AZ® 15nXT (450CPS) can be diluted with PGMEA = AZ® EBR Solvent. AZ® 15nXT (450CPS) is suitable as a mask for the galvanic deposition of e.g. Cu, Ni or Au due to its good adhesion to all common substrate materials and its high chemical stability. Developers For the development of the AZ® 15nXT (450CPS), TMAH-based developers such as the ready-to-use AZ® 326 MIF (immersion development), AZ® 726 MIF (puddle development) or AZ® 2026 MIF are recommended, which promotes residue-free development, especially with cross-linking resists, thanks to an additive. KOH- or NaOH-based developers such as the AZ® 400 K or AZ® 351B are generally not suitable for the AZ® 15nXT (450CPS). If TMAH-based developers cannot be used, an attempt with a KOH-based developer in higher concentration than usual can be considered. Removers If the resist structures have not been thermally cross-linked too much, for example through metallization, stripping or lift-off with organic solvents (acetone rinsed with isopropanol or DMSO) can be successful. For more strongly cross-linked resist structures, high-performance strippers such as the NMP-free TechniStrip NI555 or AZ® 910 Remover are recommended, or in the case of alkaline-sensitive substrate materials (such as aluminum), the TechniStrip MLO 07. Thinning/ Edge Wall Removal If the resist is to be diluted for spin coating, PGMEA = AZ® EBR Solvent is an option. PGMEA is the solvent for AZ® 15nXT (450CPS) anyway and is also recommended for edge wall removal if necessary.     Further Information Our safety data sheets and some of our technical data sheets are password-protected. You will receive the access data after completing the form. The access data for the data sheets are not your login data from our shop! MSDS: Safety Data Sheet AZ® 15nXT (450CPS) Photoresist english Safety Data Sheet AZ® 15nXT (450CPS) Photoresist german TDS: Technical Data Sheet AZ® 15nXT (450CPS) Photoresist english Technical Data Sheet AZ® 15nXT Series english Information AZ® 15nXT (450CPS) Photoresist english Application Notes: Further Information about Photoresist Processing

AZ® 3DT-102M-15 Chemically Amplified Positive Photoresist   General Information AZ® 3DT-102M-15 is a chemically amplified positive tone photoresist with a very high aspect ratio. It is intended for the use as a mask for dry etching, ion implantation, RDL and electroplating applications (Cu-compatible). It can be used with i-line steppers as well as with conventional mask aligners. The AZ® 3DT-102M-15 is intended for a thickness range of 8 - 20 µm. Product Properties Steep sidewalls Compatible with-copper plating-processes For TSV, implantation, RDL, electroplating, dry etching Chemically amplified à PEB obligatory Compatible with most photoresist stripper (e.g. AZ® 100 Remover, organic solvent based or alkaline) i-line sensitive (can be used for broadband exposure as well) Resist film thickness range ca. 8 - 20 µm Developers The recommended developers are AZ® 326 MIF or AZ® 726 MIF for the photoresist AZ® 3DT-102M-15. Removers The recommended strippers for the AZ® 3DT-102M-15 are AZ® 920 Remover, AZ® 100 Remover, TechniStrip P1316, TechniStrip P1331 and TechniStrip MLO07. Thinning/ Edge Bead Removal We recommend for thinning the AZ® EBR Solvent. Further Information MSDS: Safety Data Sheet AZ® 3DT-102M-15 Photoresist english Sicherheitsdatenblatt AZ® 3DT-102M-15 Fotolack german TDS: Technical Data Sheet AZ® 3DT-102M-15 Photoresist english Application Notes: Further Information about Photoresist Processing

AZ® 40XT Chemically Amplified Thick Photoresist   General Information AZ® 40XT is a chemically amplified, i-line sensitive ultra-thick photoresist for high aspect ratios.   Lines and spaces varying from 100 to 10 µm with a 40 µm thick AZ® 40XT at 400 mJ/cm2 exposure dose Product Features AZ® 40XT covers a resist film thickness range of approx. 15 - 50 µm. As a chemically amplified resist, the AZ® 40XT does not require rehydration between softbake and exposure, requires significantly lower exposure doses compared to non-chemically amplified resists of comparable thickness, does not release nitrogen during exposure (no bubble formation in the resist film during exposure), and has very high development rates for a thick resist. These properties help to make the entire process significantly faster and less prone to problems than with non-chemically amplified thick resists. Its good adhesion to all common substrate materials and its potential for steep resist sidewalls make it particularly suitable for galvanic molding for e.g. Cu, Ni or Au. In principle, the AZ® 40XT is only sensitive to i-line, but with correspondingly high exposure doses and resist film thicknesses, the h-line (405 nm) can also be used. It should be noted that with these chemically amplified photoresists, the post exposure bake is not optional but mandatory in order to complete the photo reaction induced during exposure and to enable subsequent development. If thinner photoresist layers than approx. 15 µm are desired, the AZ® 40XT can easily be diluted with PGMEA = AZ® EBR Solvent. If bubbles appear in the photoresist layer during the soft bake or post exposure bake, which can occur particularly with thicker photoresist layers, either a slow temperature ramp in these baking processes or a multi-stage baking process with increasing temperatures will help. If these measures are not an option, or if the formation of bubbles cannot be avoided despite this measure, we recommend using the ultra-thick photoresist AZ® IPS 6090, which is also chemically amplified. Developers TMAH-based developers such as the ready-to-use AZ® 326 MIF or AZ® 726 MIF are recommended for developing this chemically amplified photoresist. KOH- or NaOH-based developers such as the AZ® 400K or AZ® 351B are less suitable for the AZ® 40XT. Removers If the resist structures have not been thermally cross-linked by plasma processes, ion implantation or high temperatures (> approx. 140 °C), all common removers such as AZ® 100 Remover, DMSO or many other organic solvents (e.g. acetone rinsed with isopropanol) are suitable for removing the resist layer. For cross-linked resist structures, high-performance strippers such as the NMP-free TechniStrip P1316 or AZ® 920 Remover are recommended, and in the case of alkaline-sensitive substrate materials (such as aluminum), the TechniStrip MLO 07. Thinning/ Edge Wall Removal If the resist is to be diluted for spin coating, PGMEA = AZ® EBR Solvent is an option. PGMEA is the solvent for AZ® 40XT.anyway and is also recommended for edge wall removal if necessary.     Further Information Our safety data sheets and some of our technical data sheets are password-protected. You will receive the access data after completing the form. The access data for the data sheets are not your login data from our shop! MSDS: Safety Data Sheet AZ® 40XT Photoresist english Safety Data Sheet AZ® 40XT Fotolack german TDS: Technical Data Sheet AZ® 40XT Photoresist english Application Notes: Further Information about Photoresist Processing

AZ® 4533 Thick Resists with Optimized Adhesion   General Information AZ® 4533 belongs to the AZ® 4500 series of positive resists (g-, h- and i-line sensitive) in the medium resist film thickness range, the main application of which is as a resist mask for wet etching or electroplating. Product Properties AZ® 4500 resist family is not optimized for very steep resist sidewalls nor for high stability against thermal softening (softening temperature approx. 100 °C), but rather for very high adhesion to all common substrate materials. The low photoinitiator concentration of the AZ® 4500 series resists compared to thin resists (such as the AZ® 1500 series) allows the exposure of even thicker resist layers without the risk of nitrogen bubbles forming in the resist layer. AZ® 4533 is often used for etching metallic or non-metallic layers. AZ® 4533 achieves a resist film thickness of approx. 3.3 µm at a spin speed of 4000 rpm. With a correspondingly adjusted spin profile, the resist film thickness range of approx. 2.5 - 5 µm can be covered. If thinner resist layers are desired, the use of the AZ® 1500 series is recommended, or a dilution of the AZ® 4533 with PGMEA = "AZ® EBR Solvent". Thicker resist layers can be achieved with the AZ® 4562, which differs from the AZ® 4533 only in the lower solvent content. Developers For development, we recommend either TMAH-based developers such as the ready-to-use AZ® 326 MIF or 726 MIF, or the KOH-based AZ® 400K (typically 1:4 diluted with water, for faster development also slightly stronger with 1:3.5 or 1:3). On alkaline-sensitive substrate materials such as aluminum, we recommend the aluminum-compatible, undiluted "AZ® Developer”. Removers If the resist structures have not been thermally cross-linked by plasma processes, ion implantation or high temperatures (> approx. 140 °C), all common removers such as AZ® 100 Remover, DMSO or many other organic solvents (e.g. acetone rinsed with isopropanol) are suitable for removing the resist layer. For cross-linked resist structures, high-performance strippers such as the NMP-free TechniStrip P1316or AZ® 920 Remover are recommended, and in the case of alkaline-sensitive substrate materials (such as aluminum), the TechniStrip MLO 07. Thinning/ Edge Bead Removal If the resist is to be diluted for spin coating, PGMEA = AZ® EBR Solvent is the recommended solvent. PGMEA is the solvent for AZ® 4533 anyway and is also recommended for edge wall removal if necessary.     Further Information Our safety data sheets and some of our technical data sheets are password-protected. You will receive the access data after completing the form. The access data for the data sheets are not your login data from our shop! MSDS: Safety Data Sheet AZ® 4533 Photoresist english Safety Data Sheet AZ® 4533 Photoresist german TDS: Technical Data Sheet AZ® 4533 Photoresist english Application Notes: Further Information about Photoresist Processing

AZ® 4562 Thick Resists with Optimized Adhesion   General Information AZ® 4562 belongs to the AZ® 4500 series of positive resists (g-, h- and i-line sensitive) in the medium to high resist film thickness range, the main application of which is as a resist mask for wet etching or electroplating. Product Properties AZ® 4500 resist family is not optimized for very steep resist sidewalls nor for high stability against thermal softening (softening temperature approx. 100 °C), but rather for very high adhesion to all common substrate materials. The low photoinitiator concentration of the AZ® 4500 series resists compared to thin resists (such as the AZ® 1500 series) allows the exposure of even thicker resist layers without the risk of nitrogen bubbles forming in the resist layer. AZ® 4562 is often used in electroplating or for etching metallic or non-metallic layers. AZ® 4562 achieves a resist film thickness of approx. 6 µm at a spin speed of 4000 rpm. With an appropriately adjusted spin profile, the resist film thickness range of approx. 4.5 - 20 µm can be covered. If thinner resist films are required, the AZ® 4533 is recommended, which differs from the AZ® 4562 only in the higher solvent content. From approx. 10 µm, processing the AZ® 4562 becomes increasingly time-consuming: the soft bake and subsequent development take longer, rehydration between the soft bake and exposure requires more and more time, and there is also the risk of nitrogen bubbles forming during exposure. For resist film thicknesses greater than 10-20 µm, it is recommended to consider using a chemically amplified thick resist such as AZ® 12 XT (5 -20 µm resist film thickness) or IPS 6090 (> 20 µm resist film thickness), which have significantly shorter softbake and development times at the corresponding resist thickness and do not require rehydration and significantly lower exposure doses. Developers For development, we recommend either TMAH-based developers such as the ready-to-use AZ® 326 MIF or 726 MIF, or the KOH-based AZ® 400K (typically 1:4 diluted with water, for faster development also slightly stronger with 1:3.5 or 1:3). On alkaline-sensitive substrate materials such as aluminum, we recommend the aluminum-compatible, undiluted AZ® Developer. Removers If the resist structures have not been thermally cross-linked by plasma processes, ion implantation or high temperatures (> approx. 140 °C), all common removers such as AZ® 100 Remover, DMSO or many other organic solvents (e.g. acetone rinsed with isopropanol) are suitable for removing the resist layer. For cross-linked resist structures, high-performance strippers such as the NMP-free TechniStrip P1316 or AZ® 920 Remover are recommended, and in the case of alkaline-sensitive substrate materials (such as aluminum), the TechniStrip MLO 07**. Thinning/ Edge Bead Removal If the resist is to be diluted for spin coating, PGMEA = AZ® EBR Solvent is the recommended solvent. PGMEA is the solvent for AZ® 4562 anyway and is also recommended for edge removal if necessary.     Further Information Our safety data sheets and some of our technical data sheets are password-protected. You will receive the access data after completing the form. The access data for the data sheets are not your login data from our shop! MSDS: Safety Data Sheet AZ® 4562 Photoresist english Safety Data Sheet AZ® 4562 Photoresist german TDS: Technical Data Sheet AZ® 4562 Photoresist english Application Notes: Further Information about Photoresist Processing

AZ® 4999 Spray Coating   General Information AZ®4999 is a spray coating dedicated highly transparent photoresist tailored to excel on special spray coating equipment (e.g. SUSS Delta AltaSpray) where it provides defect free and conformal coatings on devices with severe topography. Thick (several to several tens of microns) and uniform resist coatings are obtained on topography such as V-grooves and trenches with optimum coverage of sharp edges. There is no accumulation of resist in trenches. The use of AZ®4999 photoresist enables high reproducibility in volume production applications. Product Properties Viscosity (at 25°C): 0.52 cSt Solids content: 4 % Absorptivity at 398 nm: 0.1 l/(g*cm) Spectral sensitivity: 310 nm – 440 nm Developers If metal ion containing developers can be used, the KOH-based AZ® 400K in a 1:4 dilution (for higher resist film thicknesses 1:3.5 - 1:3 diluted possible) is a suited developer. If metal ion free developers have to be used, we recommend the TMAH-based AZ® 2026 MIF developer (undiluted). Removers For non cross-linked resist films the AZ® 100 Remover, DMSO or other common organic solvents cab be used as stripper. If the resist film is crosslinked (e. g. by high temperature steps > 140°C, during plasma processes such as dry etching, or during ion implantation), we recommend the NMP-free TechniStrip P1316 as remover. AZ® 920 Remover can be a good choice as well, in case of harsh treated, hard to remove resist residuals. Thinning/ Edge Bead Removal We recommend for thinning and edge bead removal the products AZ® EBR Solvent or PGMEA. Further Information MSDS: Safety Data Sheet AZ® 4999 Photoresist english Sicherheitsdatenblatt AZ® 4999 Fotolack german TDS: Technical Data Sheet AZ® 4999 Photoresist english Application Notes: Further Information about Photoresist Processing

AZ® 5209E Image Reversal Resist for High Resolution   General Information This special photoresist is the thinner version of the AZ® 5200E series intended for lift-off techniques which call for a negative side wall profile. The reversal bake moderately cross-links the exposed resist making the developed structures thermally stable up to approx. 130°C. Due to the comparably low resist film thickness of ~ 0.9 µm, the process parameter window for an undercut is rather small thus requiring some optimizations in the exposure dose and the reversal bake parameters. Therefore, if the resolution required is not in the sub-µm range, a thicker resist such as the AZ® LNR-003 (next section), or the AZ® nLOF 2000 negative resists might be a good alternative. Product Properties Very high resolution as a positive resist as well as a negative resist Possible negative sidewall profile in image reversal mode Compatible with all common developers (NaOH-, KOH- or TMAH-based) Compatible with all common strippers (e. g. with AZ® 100 Remover, organic solvents, or aqueous alkaline) h- and i-line sensitive (approx. 320 - 405 nm) Resist film thickness range approx. 0.7 - 1.2 µm High thermal stability especially in image reversal mode Developers If metal ion containing developers can be used, the NaOH-based AZ® 351B in a 1:4 dilution (for a required resolution < 1 µm 1:5 dilution recommended) is a suited developer. The KOH-based AZ® 400K (also 1:4 - 1:5 diluted) is also possible. If metal ion free developers have to be used, we recommend the TMAH-based AZ® 726 MIF or AZ® 326 MIF developer, normally undiluted, or - for maximum resolution - moderately 3:1 - 2:1 (3 parts Developer :1 part of DI-Water) diluted with water. Removers For non cross-linked resist films the AZ® 100 Remover, DMSO or other common organic solvents cab be used as stripper. If the resist film is crosslinked (e. g. by high temperature steps > 140°C, during plasma processes such as dry etching, or during ion implantation), we recommend the NMP-free TechniStrip P1316 as remover. AZ® 920 Remover can be a good choice as well, in case of harsh treated, hard to remove resist residuals. Thinning/ Edge Bead Removal We recommend for thinning and edge bead removal the products AZ® EBR Solvent or PGMEA. Further Information MSDS: Safety Data Sheet AZ® 5209-E Photoresist english Sicherheitsdatenblatt AZ® 5209-E Fotolack german TDS: Technical Data Sheet AZ® 5209-E Photoresist english Application Notes: Further Information about Photoresist Processing

AZ® 5214E Image Reversal Resist for High Resolution   General Information This special photoresist is intended for lift-off techniques which call for a negative side wall profile. The reversal bake moderately cross-links the exposed resist making the developed structures thermally stable up to approx. 130°C. Due to the comparably low resist film thickness of ~1.4 µm, the process parameter window for an undercut is rather small thus requiring some optimizations in the exposure dose and the reversal bake parameters. Therefore, if the resolution required is not in the sub-µm range, a thicker resist such as the AZ® LNR-003 (next section), or the AZ® nLOF 2000 negative resists might be a good alternative. The undercut of AZ® 5214E attained under optimized process parameters. Product Properties Very high resolution as a positive resist as well as a negative resist Possible negative sidewall profile in image reversal mode Compatible with all common developers (NaOH-, KOH- or TMAH-based) Compatible with all common strippers (e. g. with AZ® 100 Remover, organic solvents, or aqueous alkaline) h- and i-line sensitive (approx. 320 - 405 nm) Resist film thickness range approx. 1.0 – 1.8 µm High thermal stability especially in image reversal mode Developers If metal ion containing developers can be used, the NaOH-based AZ® 351B in a 1:4 dilution (for a required resolution < 1 µm 1:5 dilution recommended) is a suited developer. The KOH-based AZ® 400K (also 1:4 - 1:5 diluted) is also possible. If metal ion free developers have to be used, we recommend the TMAH-based AZ® 726 MIF or AZ® 326 MIF developer, normally undiluted, or - for maximum resolution - moderately 3:1 - 2:1 ( 3 parts Developer :1 part of DI-Water) diluted with water. Removers For non cross-linked resist films the AZ® 100 Remover, DMSO or other common organic solvents cab be used as stripper. If the resist film is crosslinked (e. g. by high temperature steps > 140°C, during plasma processes such as dry etching, or during ion implantation), we recommend the NMP-free TechniStrip P1316 as remover. AZ® 920 Remover can be a good choice as well, in case of harsh treated, hard to remove resist residuals. Thinning/ Edge Bead Removal We recommend for thinning and edge bead removal the products AZ® EBR Solvent or PGMEA. Further Information MSDS: Safety Data Sheet AZ® 5214E Photoresist english Sicherheitsdatenblatt AZ® 5214E Fotolack german TDS: Technical Data Sheet AZ® 5214E Photoresist english Application Notes: Further Information about Photoresist Processing

AZ® ECI 3007 High Resolution with Broad Process Window   General Information AZ® ECI 3007 belongs to the AZ® ECI 3000 series of positive thin resists (g-, h- and i-line sensitive), whose main applications are as a resist mask for dry etching, RIE, ion implantation or lift-off processes. Product Properties AZ® ECI 3000 resist family is optimized for steep resist sidewalls and high stability against thermal softening (softening temperature approx. 125 °C). AZ® ECI 3000 resists require a significantly lower exposure dose compared to other positive resists, but still develop quickly. AZ® ECI 3007 is the thinnest member of this resist series with a resist film thickness of approx. 700 nm at 3000 rpm. This resist is often used for dry etching, RIE or lift-off processes and, under optimized process parameters, allows a resolution well in the sub-micrometer range. If such a high resolution is not required, a slightly thicker resist from this series (for example AZ® ECI 3012, AZ® ECI 3027) can be useful. If necessary, the AZ® ECI 3007 can easily be further diluted with PGMEA = AZ® EBR Solvent. Paints from the AZ® 1500 or 4500 series are recommended for applications with high requirements for very good resist adhesion such as wet etching and galvanic deposition. Developers For development, we recommend either TMAH-based developers such as AZ® 326 MIF or AZ® 726 MIF, the NaOH-based AZ® 351B, and if the requirements for selectivity are not too high, the KOH-based AZ® 400K. With AZ® 351B or AZ® 400K, it may be advisable to work with a higher diluted developer (for example 1:5 to 1:6) instead of the usual 1: 4 dilution to achieve very fine resist structures or better controllable development times. On alkaline-sensitive substrate materials such as aluminum, we recommend the aluminum-compatible AZ® Developer in a 1:1 dilution. Removers If the resist structures have not been thermally cross-linked by plasma processes, ion implantation or high temperatures (> approx. 140 °C), all common removers such as AZ® 100 Remover, DMSO or many other organic solvents (e.g. acetone rinsed with isopropanol) are suitable for removing the resist layer. For cross-linked resist structures, high-performance strippers such as the NMP-free TechniStrip P1316 or AZ® 920 Remover are recommended, and in the case of alkaline-sensitive substrate materials (such as aluminum), the TechniStrip MLO 07. Thinning/ Edge Bead Removal PGMEA = AZ® EBR Solvent can generally be used as a thinner for spin coating, which can also be used to remove edge ridges if necessary.     Further Information Our safety data sheets and some of our technical data sheets are password-protected. You will receive the access data after completing the form. The access data for the data sheets are not your login data from our shop! MSDS: Safety Data Sheet AZ® ECI 3007 Photoresist english Safety Data Sheet AZ® ECI 3007 Photoresist german TDS: Technical Data Sheet AZ® ECI 3000 Series english Application Notes: Further Information about Photoresist Processing

AZ® ECI 3012 High Resolution with Broad Process Window   General Information AZ® ECI 3012 belongs to the AZ® ECI 3000 series of positive thin resists (g-, h- and i-line sensitive), whose main applications are as a resist mask for dry etching, RIE, ion implantation or lift-off processes.   450 nm resist lines with the AZ® ECI 3012 at approx. 1.2 µm film thickness.   Product Properties AZ® ECI 3000 resist family is optimized for steep resist sidewalls and high stability against thermal softening (softening temperature approx. 125 °C). AZ® ECI 3000 resists require a significantly lower exposure dose compared to other positive resists, but still develop quickly. AZ® ECI 3012 covers the resist film thickness range of approx. 1.3 µm at 3000 rpm with adapted spin profiles. This resist is often used for dry etching, RIE or lift-off processes and allows a resolution in the sub-micrometer range under optimized process parameters. If such a high resolution is not required, a slightly thicker resist from this series (for example AZ® ECI 3027) can be useful. If thinner resist layers are required, we recommend AZ® ECI 3007, or alternatively a dilution of AZ® ECI 3012 with PGMEA = AZ® EBR Solvent. For applications with high requirements for very good resist adhesion, such as wet etching and galvanic deposition, we recommend resists from the AZ® 1500 or 4500 series. Developers For development, we recommend either TMAH-based developers such as AZ® 326 MIF, or 726 MIF, the NaOH-based AZ® 351B, and if the requirements for selectivity are not too high, the KOH-based AZ® 400K. with AZ® 351B or AZ® 400K, it may be advisable to work with a higher diluted developer (for example 1:5 to 1:6) instead of the usual 1: 4 dilution to achieve very fine resist structures or better controllable development times. On alkaline-sensitive substrate materials such as aluminum, we recommend the aluminum-compatible AZ® Developer in a 1:1 dilution. Removers If the resist structures have not been thermally cross-linked by plasma processes, ion implantation or high temperatures (> approx. 140 °C), all common removers such as AZ® 100 Remover, DMSO or many other organic solvents (e.g. acetone rinsed with isopropanol) are suitable for removing the resist layer. For cross-linked resist structures, high-performance strippers such as the NMP-free TechniStrip P1316 or AZ® 920 Remover, are recommended, and in the case of alkaline-sensitive substrate materials (such as aluminum), the TechniStrip MLO 07. Thinning/ Edge Bead Removal PGMEA = AZ® EBR Solvent can generally be used as a thinner for spin coating, which can also be used to remove edge ridges if necessary.     Further Information Our safety data sheets and some of our technical data sheets are password-protected. You will receive the access data after completing the form. The access data for the data sheets are not your login data from our shop! MSDS: Safety Data Sheet AZ® ECI 3012 Photoresist english Safety Data Sheet AZ® ECI 3012 Photoresist german TDS: Technical Data Sheet AZ® ECI 3012 Photoresist english Technical Data Sheet AZ® ECI 3000 Series english Application Notes: Further Information about Photoresist Processing

AZ® ECI 3027 High Resolution with Broad Process Window   General Information AZ® ECI 3027 belongs to the AZ® ECI 3000 series of positive resists (g-, h- and i-line sensitive), whose main applications are as a resist mask for dry etching, RIE, ion implantation or lift-off processes.   900 nm resist lines with the AZ® ECI 3027 at approx. 2.7 µm resist film thickness.   Product Properties AZ® ECI 3000 resist family is optimized for steep resist sidewalls and high stability against thermal softening (softening temperature approx. 125 °C). AZ® ECI 3000 resists require a significantly lower exposure dose compared to other positive resists, but still develop quickly. AZ® ECI 3027 covers a resist film thickness of approx. 2.7 µm at 3000 rpm with adapted spin profiles and covers the resist film thickness range of approx. 2 - 4 µm. This resist is often used for dry etching, RIE or lift-off processes. If a resolution in the sub-micrometer range is required, a slightly thinner resist from this series (for example AZ® ECI 3012 or AZ® ECI 3007) may be useful, or alternatively a dilution of the AZ® ECI 3027 with PGMEA = AZ® EBR Solvent. For applications with high requirements for very good resist adhesion such as wet etching and galvanic deposition, resists from the AZ® 1500 or 4500 series are recommended. Developers For development, we recommend either TMAH-based developers such as AZ® 326 MIF or 726 MIF, the NaOH-based AZ® 351B, and if the requirements for selectivity are not too high, the KOH-based AZ® 400K. With AZ® 351B or AZ® 400K, it may be advisable to work with a higher diluted developer (for example 1:5 to 1:6) instead of the usual 1:4 dilution to achieve very fine resist structures or better controllable development times. On alkaline-sensitive substrate materials such as aluminum, we recommend the aluminum-compatible AZ® Developer in a 1:1 dilution. Removers If the resist structures have not been thermally cross-linked by plasma processes, ion implantation or high temperatures (> approx. 140 °C), all common removers such as AZ® 100 Remover, DMSO or many other organic solvents (e.g. acetone rinsed with isopropanol) are suitable for removing the resist layer. For cross-linked resist structures, high-performance strippers such as the NMP-free TechniStrip P1316 or AZ® 920 Remover are recommended, and in the case of alkaline-sensitive substrate materials (such as aluminum), the TechniStrip MLO 07. Thinning/ Edge Bead Removal PGMEA = AZ® EBR Solvent can generally be used as a thinner for spin coating, which can also be used to remove edge ridges if necessary.     Further Information Our safety data sheets and some of our technical data sheets are password-protected. You will receive the access data after completing the form. The access data for the data sheets are not your login data from our shop! MSDS: Safety Data Sheet AZ® ECI 3027 Photoresist english Safety Data Sheet AZ® ECI 3027 Photoresist german TDS: Technical Data Sheet AZ® ECI 3000 Series english Application Notes: Further Information about Photoresist Processing

AZ® IPS-6090 Positive Thick Resist   General Information AZ® IPS-6090 is a chemically amplified, i-line sensitive ultra-thick photoresist for high aspect ratios.   AZ® IPS 6050 (80 µm resist film thickness)   Product Properties AZ® IPS-6090 covers a resist film thickness range of approx. 15 - 50 µm. As a chemically amplified resist, the AZ® IPS-6090 does not require rehydration between softbake and exposure, requires significantly lower exposure doses compared to non-chemically amplified resists of comparable thickness, does not release nitrogen during exposure (no bubble formation in the resist film during exposure), and has very high development rates for a thick resist. These properties help to make the entire process significantly faster and less prone to problems than with non-chemically amplified thick resists. Its good adhesion to all common substrate materials and its potential for steep resist sidewalls make it particularly suitable for galvanic molding. In principle, the AZ® IPS-6090 is only sensitive to i-line, but with correspondingly high exposure doses and resist film thicknesses, the h-line (405 nm) can also be used. It should be noted that with these chemically amplified photoresists, the post exposure bake is not only optional, but absolutely necessary in order to complete the photoreaction induced during exposure and to enable subsequent development. If thinner photoresist layers than approx. 15 µm are desired, the AZ® IPS 6090 can easily be diluted with PGMEA = AZ® EBR Solvent. Developers TMAH-based developers such as the ready-to-use AZ® 326 MIF or AZ® 726 MIF are recommended for developing this chemically amplified photoresist. KOH- or NaOH-based developers such as the AZ® 400K.or AZ® 351B are less suitable for the AZ® 40 XT. Removers If the resist structures have not been thermally cross-linked by plasma processes, ion implantation or high temperatures (> approx. 140 °C), all common removers such as AZ® 100 Remover, DMSO or many other organic solvents (e.g. acetone rinsed with isopropanol) are suitable for removing the resist layer. For cross-linked resist structures, high-performance strippers such as the NMP-free TechniStrip P1316 or AZ® 920 Remover are recommended, and in the case of alkaline-sensitive substrate materials (such as aluminum), the TechniStrip MLO 07. Thinning/ Edge Bead Removal If the resist is to be diluted for spin coating, PGMEA = AZ® EBR Solvent is an option. PGMEA is the solvent for AZ® IPS-6090 anyway and is also recommended for edge ridge removal if necessary.     Further Information Our safety data sheets and some of our technical data sheets are password-protected. You will receive the access data after completing the form. The access data for the data sheets are not your login data from our shop! MSDS: Safety Data Sheet AZ® IPS-6090 Photoresist english Safety Data Sheet AZ® IPS-6090 Photoresist german TDS: Technical Data Sheet AZ® IPS-6090 english Information AZ® IPS-6090 english Application Notes: Further Information about Photoresist Processing

AZ® LNR-003 Negative Resist for Lift-off Applications   General Information The i-line sensitive negative resist AZ® LNR 003 with a resist film thickness of approx. 2 - 4 µm is a resist optimized primarily for lift-off applications due to its adjustable strong undercut. Product Properties AZ® LNR 003 covers a resist film thickness range of - depending on the spin speed - approx. 2 - 4 µm. It is only i-line sensitive and requires a post exposure bake after exposure to complete the cross-linking induced during exposure. The developed resist structures are, as desired for lift-off applications, pronounced negative even with low resist film thicknesses, since the strong absorption means that the upper resist areas receive a much higher dose during exposure and thus cross-link more strongly than the resist areas close to the substrate. The undercut can be adjusted over a relatively large range using the exposure dose (lower dose = stronger undercut) and the duration of overdevelopment. This also enables critical lift-off applications (for example sputtered or thicker layers) to be implemented. However, it should be noted that too strong an undercut can lead to narrow resist structures lifting off the substrate during development. If even thinner resist layers are required, the LNR 003 can be diluted with PGMEA = AZ® EBR Solvent, for which we offer an appropriately diluted version (AZ® LNR-003 diluted). For thicker layers > 3 µm resist thickness, the AZ® nLOF 2000 series is recommended. Developers AZ® 326 MIF (immersion development), AZ® 726 MIF (puddle development) or AZ® 2026 MIF (which has an additive that promotes residue-free development, especially with cross-linking resists) are recommended for developing the AZ® LNR 003. KOH- or NaOH-based developers such as AZ® 400K or AZ® 351B are generally not suitable for the AZ® LNR 003. If TMAH-based developers cannot be used, an attempt with a normal or more aggressive KOH-based developer can be considered. Removers If the resist structures have not been thermally cross-linked too much, for example through metallization, stripping or lift-off with organic solvents (acetone rinsed with isopropanol or DMSO) can be successful. For more strongly cross-linked resist structures, high-performance strippers such as the NMP-free TechniStrip NI555 or AZ® 920 Remover are recommended, or in the case of alkaline-sensitive substrate materials (such as aluminum), the TechniStrip MLO 07. Thinning/ Edge Bead Removal If the resist is to be diluted for spin coating, PGMEA = AZ® EBR Solventis an option. PGMEA is the solvent for AZ® LNR 003 anyway and is also recommended for edge removal if necessary.     Further Information Our safety data sheets and some of our technical data sheets are password-protected. You will receive the access data after completing the form. The access data for the data sheets are not your login data from our shop! MSDS: Safety Data Sheet AZ® LNR-003 Photoresist english Safety Data Sheet AZ® LNR-003 Photoresist german TDS: Technical Data Sheet AZ® LNR-003 english Information AZ® LNR-003 english Application Notes: Further Information about Photoresist Processing

AZ® LNR-003 diluted – 1:0.3 with PGMEA Negative Resist for Lift-off Applications   General Information The i-line sensitive negative resist AZ® LNR 003 with a resist film thickness of approx. 1 - 2 µm is a resist optimized primarily for lift-off applications due to its adjustable strong undercut. Product Properties AZ® LNR 003 covers a resist film thickness range of - depending on the spin speed - approx. 1 - 2 µm. It is only i-line sensitive and requires a post exposure bake after exposure to complete the cross-linking induced during exposure. The developed resist structures are, as desired for lift-off applications, pronounced negative even with low resist film thicknesses, since the strong absorption means that the upper resist areas receive a much higher dose during exposure and thus cross-link more strongly than the resist areas close to the substrate. The undercut can be adjusted over a relatively large range using the exposure dose (lower dose = stronger undercut) and the duration of overdevelopment. This also enables critical lift-off applications (for example sputtered or thicker layers) to be implemented. However, it should be noted that too strong an undercut can lead to narrow resist structures lifting off the substrate during development. If even thinner resist layers are required, the AZ® LNR 003 can be diluted with PGMEA = AZ® EBR Solvent, whereby it becomes increasingly difficult to achieve an undercut with based resist layers. For thicker resist layers, the higher viscosity version of the AZ® LNR 003 is recommended or for > 3 µm resist film thickness the AZ® nLOF 2000 series. Developers TMAH-based developers such as the ready-to-use AZ® 326 MIF (immersion development), AZ® 726 MIF (puddle development) or AZ® 2026 MIF (which has an additive that promotes residue-free development, especially with cross-linking resists) are recommended for developing the AZ® LNR 003. KOH- or NaOH-based developers such as AZ® 400K or AZ® 351B are generally not suitable for the AZ® LNR 003. If TMAH-based developers cannot be used, an attempt with a normal or more aggressive KOH-based developer can be considered. Removers If the resist structures have not been thermally cross-linked too much, for example through metallization, stripping or lift-off with organic solvents (acetone rinsed with isopropanol or DMSO) can be successful. For more strongly cross-linked resist structures, high-performance strippers such as the NMP-free TechniStrip NI555 or AZ® 920 Remover are recommended, or in the case of alkaline-sensitive substrate materials (such as aluminum), the TechniStrip MLO 07. Thinning/ Edge Bead Removal If the resist is to be diluted for spin coating, PGMEA = AZ® EBR Solventis an option. PGMEA is the solvent for AZ® LNR 003 anyway and is also recommended for edge removal if necessary.     Further Information Our safety data sheets and some of our technical data sheets are password-protected. You will receive the access data after completing the form. The access data for the data sheets are not your login data from our shop! MSDS: Safety Data Sheet AZ® LNR-003 Photoresist english Safety Data Sheet AZ® LNR-003 Photoresist german TDS: Technical Data Sheet AZ® LNR-003 english Information AZ® LNR-003 english Application Notes: Further Information about Photoresist Processing
