Ammonia Solution NH4OH   General Information Mixed with H2O2, Ammonia is an ingredient of many etching mixtures for metals such as copper, silver or aluminum. Our Ammonia solution (28 - 30%) is available in VLSI-quality, which is the usual purity grades applied in semiconductor processing and micro-electronics. Data on selectivity and compatibility are manufacturer information and do not claim to be complete. Please contact us for further details. Further Information MSDS: Safety Data Sheet Ammonium Hydroxide Solution (VLSI) 28-30% english Specs: Specs Ammonium Hydroxide Solution (VLSI) 28-30% Application Notes: Wet Etching english Nasschemisches Ätzen german

Au etch 200 Gold Etchant   General Information Au etch 200 is a non-hazardous, cyanide-free, slightly alkaline etchant for Au. The etchant is used for the wet-chemical patterning of Au layers with selectivity to metals like Pt, Ni, Cr, Ti, Al. Common areas of use for semiconductor fabrication or micro system technology. Product Properties Low undercut (in the range of the layer thickness), minimum feature size < 1 µm Selectivity to many materials, e.g. common metals used in electroplating industry Available in different purity grades Compatible to resist masking Not hazardous substance and easy to handle Selectivity Au etch 200 is compatible/etches selective to following materials: Resists: common Novolak as masking resist (e.g. AZ® Photoresist) Metals: no attack on Pt, Ni, Cr, Ti, Al, Ta Metals: attacked Au, Cu Semiconductor materials: Si, SiO2, Si3N4 Data on selectivity and compatibility are manufacturer information and do not claim to be complete. Please contact us for further details. Etching Rate Under normal condition, the etching rate is around 40 nm/min (at 50°C). The mixed etching solution is stable over time and can be used multiple times depending on the requirements of application. It is recommended to dispose the solution at the latest, when the etching rate has changed by 20%. Further Information MSDS: Safety Data Sheet Au etch 200 english Sicherheitsdatenblatt Au etch 200 german TDS: Technical Data Sheet Au etch 200 english Technical Data Sheet Au etch 200 german Application Notes: Wet Etching english Nasschemisches Ätzen german Wet Etching of Metals english Nasschemisches Ätzen von Metallen german Further Information about Processing

BOE 7:1 Buffered Oxide Etch   General Information BOE is mainly used for etching glasses, quartz and SiO2 films. We supply BOE 7:1 = buffered hydrofluoric acid (HF : NH4F = 12.5 : 87.5%) in VLSI-quality, which is the usual purity grades applied in semiconductor processing and micro-electronics. NOTE: BOE must be stored and transported above +12.5°C. Below this critical temperature of 12.5°C the material forms particles (little crystals). Since these crystals have a higher density, they will accumulate at the bottom of the bottle and will only be completely re-dissolved when the material is stored at temperatures of 30 - 35°C for some days. After this procedure the crystals should be re-dissolved completely and the BOE can be then used without restrictions. Further Information MSDS: Safety Data Sheet BOE 7:1 (VLSI) english Sicherheitsdatenblatt BOE 7:1 (VLSI) german Specs: Specs BOE 7:1 (VLSI) Application Notes: Wet Etching english Nasschemisches Ätzen german Further Information about Processing

Cr etch 210 Chromium Etchant   General Information Cr etch 210 is an alkaline etchant for Cr. The etchant is used for the wet-chemical patterning or removal of thin Cr layers with selectivity to metals like Au, Sn, Pt, Cu, Ni, Ti, Ta. Common areas of use are for semiconductor fabrication or microsystem technology, e.g. for the removal or patterning of a Cr barrier or adhesion layer in a plating seed stack. Product Properties Low undercut (in the range of the layer thickness), minimum feature size < 1µm Selectivity to many materials, e.g. common metals used in electroplating industry Available in different purity grades Compatible to resist mask Use at room temperature Increase of the etching rate by increased temperature up to 40°C Selectivity Cr etch 210 is compatible/etches selective to following materials: Resists: common Novolak as masking resist (e.g. AZ® Photoresist) Metals: no attack on Au, Sn, Pt, Cu, Ni, Ti, Ta Metals: attacked Cr Semiconductor materials: Si, SiO2, Si3N4 Data on selectivity and compatibility are manufacturer information and do not claim to be complete. Please contact us for further details. Etching Rate Under normal condition, the etching rate is around 10 to 15nm/min at 40 °C (accordingly lower at room temperature). A sputtered 30nm Cr layer is etched in about 180 seconds. The mixed etching solution is stable over time and can be used multiple times depending on the requirements of application. It is recommended to dispose the solution at the latest, when the etching rate has changed by 20%. Further Information MSDS: Safety Data Sheet Cr etch 210 english Sicherheitsdatenblatt Cr etch 210 german TDS: Technical Data Sheet Cr etch 210 english Technical Data Sheet Cr etch 210 german Application Notes: Wet Etching english Nasschemisches Ätzen german Wet Etching of Metals english Nasschemisches Ätzen von Metallen german Further Information about Processing

Cu etch 100 Copper Etchant   General Information Cu etch 100 is an alkaline etchant for Cu and is used for the wet-chemical removal of Cu layers with selectivity to metals like Ni, Au, Cr, Sn, Ti. Common areas of use are for semiconductor fabrication or microsystem technology. Product Properties High etching rate and rate of under etching with Cu as sacrificial layer Selectivity to many materials, e.g. common metals used in electroplating industry Available in different purity grades Compatible to resist masking Usage at room temperature Selectivity Cu etch 100 is compatible/etches selective to following materials: Resists: common Novolak as masking resist (e.g. AZ® Photoresist) Metals: no attack on Ni, Au, Cr, Sn, Ti, Pt, Ta Metals: attacked Cu, TiW, Ag, Zn Semiconductor materials: Si, SiO2, Si3N4 Data on selectivity and compatibility are manufacturer information and do not claim to be complete. Please contact us for further details. Etching Rate Under normal condition, the etching rate is around 3 to 3.5µm/min (at RT). The mixed etching solution is not stable over time (mixture of two components), but can be used multiple times depending on the requirements of application. It is recommended to dispose the solution at the latest, when the etching rate has changed by 20%. Further Information MSDS: Safety Data Sheet Cu etch 100 english Sicherheitsdatenblatt Cu etch 100 german TDS: Technical Data Sheet Cu etch 100 english Technical Data Sheet Cu etch 100 german Application Notes: Wet Etching english Nasschemisches Ätzen german Wet Etching of Metals english Nasschemisches Ätzen von Metallen german Further Information about Processing

Cu etch 150 Copper Etchant   General Information Cu etch 150 is an alkaline etchant for Cu and is used for the wet-chemical removal of Cu layers with selectivity to metals like Ni, Au, Cr, Sn, Ti. Common areas of use are for semiconductor fabrication or microsystem technology. Product Properties Selectivity to many materials, e.g. common metals used in electroplating industry Available in different purity grades Compatible to resist masking Usage at room temperature Selectivity Cu etch 150 is compatible/etches selective to following materials: Resists: common Novolak as masking resist (e.g. AZ® Photoresist) Metals: no attack on Ni, Au, Cr, Sn, Ti, Pt, Ta Metals: attacked Cu, TiW, Ag, Zn Semiconductor materials: Si, SiO2, Si3N4 Data on selectivity and compatibility are manufacturer information and do not claim to be complete. Please contact us for further details. Etching Rate Under normal condition, the etching rate is around 100 to 150nm/min (at RT). The mixed etching solution is not stable over time (mixture of two components), but can be used multiple times depending on the requirements of application. It is recommended to dispose the solution at the latest, when the etching rate has changed by 20%. Further Information MSDS: Safety Data Sheet Cu etch 150 english Sicherheitsdatenblatt Cu etch 150 german TDS: Technical Data Sheet Cu etch 150 english Technical Data Sheet Cu etch 150 german Application Notes: Wet Etching english Nasschemisches Ätzen german Wet Etching of Metals english Nasschemisches Ätzen von Metallen german Further Information about Processing

Cu etch 200 UBM Copper Etchant   General Information Cu etch 200 UBM is a slightly alkaline etchant for Cu and is used for the wet-chemical removal of Cu seed layers with selectivity to metals like Ni, Au, Cr, Sn, Ti, Al. Common areas of use are for semiconductor fabrication or microsystem technology especially for the removal of seed layers after the plating of under-bump-metallization (UBM). Product Properties Selectivity to many materials, e.g. common metals used in electroplating industry Very small dimension lost Available in different purity grades Compatible to resist masking Usage at room temperature Selectivity Cu etch 200 UBM is compatible/etches selective to following materials: Resists: common Novolak as masking resist (e.g. AZ® Photoresist) Metals: no attack on Ni, Au, Cr, Sn, Ti, Al, Pt Metals: attack on Cu, Ag Semiconductor materials: Si, SiO2, Si3N4 Data on selectivity and compatibility are manufacturer information and do not claim to be complete. Please contact us for further details. Etching Rate Under normal condition, the etching rate is around 200 to 250nm/min (at RT). The etching solution stable over time and can be used multiple times depending on the requirements of application. It is recommended to dispose the solution at the latest, when the etching rate has changed by 20%. Further Information MSDS: Safety Data Sheet Cu etch 200 english Sicherheitsdatenblatt Cu etch 200 german TDS: Technical Data Sheet Cu etch 200 english Technical Data Sheet Cu etch 200 german Application Notes: Wet Etching english Nasschemisches Ätzen german Wet Etching of Metals english Nasschemisches Ätzen von Metallen german Further Information about Processing

Hydrogene Peroxide H2O2   General Information H2O2 is an ingredient of the Piranha-etch, RCA-1 and RCA-2 etching solutions, as well as etching solutions for various III/V-semiconductors. H2O2 (30%) is available in VLSI-quality, which is the usual purity grades applied in semiconductor processing and micro-electronics. Further Information MSDS: Safety Data Sheet Hydrogen Peroxide 30% (VLSI) english Sicherheitsdatenblatt Hydrogen Peroxide 30% (VLSI) german Specs: Specs Hydrogen Peroxide 30% (VLSI) Application Notes: Wet Etching english Nasschemisches Ätzen german Further Information about Processing

TechniEtch™ACI2 Gold Etchant   General Information TechniEtch™ACI2 is a highly effective and selective gold stripper. TechniEtch™ACI2 is an Iodine based Gold etchant, containing particular additives that greatly enhance stability and metal loading capability compared to conventional I2/I3 - based solutions . Product Properties High etch rate at room temperature Low surface tension for enhanced wetting property High stability even in presence of metal contamination (Cu, Ni…). Loading & bath life independent of the solution Cu contamination level (up to 1g/l) Enlarged loading capacity compared to standard I2/KI based solutions. Better process controllability/reliability. Low Toxicity compared to cyanide and HF/HNO3 based solutions Selectivity TechniEtch™ACI2 is compatible/etches selective to following materials: Metals: no attack on Ni, Al, Ti, TiN Metals: attack on Au, Cu, Sn, Pt, W Semiconductor materials: Si, SiO2, Si3N4 Data on selectivity and compatibility are manufacturer information and do not claim to be complete. Please contact us for further details. Further Information MSDS: Safety Data TechniEtch™ACI2 (VLSI) english Sicherheitsdatenblatt TechniEtch™ACI2 (VLSI) german TDS: Technical Data Sheet TechniEtch™ACI2 (VLSI) english Specs: Specs TechniEtch™ACI2 (VLSI) Application Notes: Wet Etching english Nasschemisches Ätzen german Wet Etching Metals english Nasschemisches Ätzen von Metallen german Further Information about Processing

TechniEtch Al80 Aluminium Etchant   General Information TechniEtch Al80 is a ready-to-use etching mixture based on phosphoric acid, nitric acid and acetic acid for aluminium etching. Our aluminium etchant TechniEtch Al80 has the composition H3PO4 : HNO3 : CH3COOH* : H2O = 80% : 5% : 5% : 10% comes in MOS quality. Product Properties High etch rate at room temperature. High stability even in presence of metal contamination Loading & bath life mainly dependent of process temperature, tool and extraction flow Selectivity TechniEtch Al80 is compatible/etches selective to following materials: Metals: no attack on Au, Pt Metals: attack on Al Data on selectivity and compatibility are manufacturer information and do not claim to be complete. Please contact us for further details. Further Information MSDS: Safety Data TechniEtch Al80 (MOS) english Sicherheitsdatenblatt TechniEtch Al80 (MOS) german TDS: Technical Data Sheet TechniEtch Al80 (MOS) english Specs: Specs TechniEtch Al80 (MOS) Application Notes: Wet Etching english Nasschemisches Ätzen german Wet Etching Metals english Nasschemisches Ätzen von Metallen german Further Information about Processing

TechniEtch™ CN10 Copper and Nickel Etchant   General Information TechniEtch™ CN10 is a copper and nickel etchant, which is a mixture of nitric- and phosphoric acid. The etching process should be carried out with an addition of 8-16 % Hydrogenperoxide (30 %). At 25° C the etching rate is approx. 0.3-0.4 µm per minute. Without the Addition of Hydrogenperoxide the etching rate is significantly lower and less homogenous.   TechniEtch CN10 (90 s RT Cu seed removal) Product Properties Better process controllability/reliability High stability even in presence of metal contamination Selectivity TechniEtch™ CN10 is compatible/etches selective to following materials: Metals: no attack on Ti, TiN Metals: attack on Cu, Ni Data on selectivity and compatibility are manufacturer information and do not claim to be complete. Please contact us for further details. Further Information MSDS: Safety Data TechniEtch™ CN10 (MOS) english Sicherheitsdatenblatt TechniEtch™ CN10 (MOS) german TDS: TF Technical Data Sheet TechniEtch™ CN10 (MOS) english MC Technical Data Sheet TechniEtch™ CN10 (MOS) english Mixing TechniEtch™ CN10 (MOS) english Specs: Specs TechniEtch™ CN10 (MOS) Application Notes: Wet Etching english Nasschemisches Ätzen german Wet Etching Metals english Nasschemisches Ätzen von Metallen german Further Information about Processing

TechniEtch Cr01 Chromium Etchant   General Information TechniEtch Cr01 is a ready-to-use etching mixture based on ceric ammonium nitrate and perchloric acid for Cr etching. TechniEtch Cr01 consists of ceric ammonium nitrate : Perchloric acid : water = 10.9% : 4.25% : 84.85% with an etching rate of about 60 nm/minute at room temperature comes in VLSI quality. Product Properties Cr etch rate at room temperature 60-100 nm/min Al, Ti, W, Ni @ RT from 10nm/min to 200 nm/min Cu, Ag, V are heavily etched > 200 nm/min Au, Pd, Pt are compatible Compatible with positive tone resin Can be diluted down to adjust Cr etch rate Selectivity TechniEtch Cr01 is compatible/etches selective to following materials: Metals: no attack on Au, Pd, Pt Metals: attack on Cr, Fe, Mo, Ni, Al, Ti, W, Cu, Ag, V, Co, Mg, Mn, Sn Data on selectivity and compatibility are manufacturer information and do not claim to be complete. Please contact us for further details. Further Information MSDS: Safety Data TechniEtch Cr01 (VLSI) english Sicherheitsdatenblatt TechniEtch Cr01 (VLSI) german TDS: Technical Data Sheet TechniEtch Cr01 (VLSI) english Specs: Specs TechniEtch Cr01 (VLSI) Application Notes: Wet Etching english Nasschemisches Ätzen german Wet Etching Metals english Nasschemisches Ätzen von Metallen german Further Information about Processing

TechniEtch™ TBR19 Concentrate Ti, TiW and TiN Etchant   General Information TechniEtch™ TBR19 is a low undercut Ti etch chemistry concentrate for Cu bump pillars for self-mixing. TechniEtch™ TBR19 concentrate is compatible with most under bump metallization (UBM) and copper pillar integration materials such as Cu, Al, Ni and alloys, glass, organic substrate and most plastics like polypropylene, HDPE, PFA, PTFE Kalrez, PEEK, PE. The etching rate at 50°C is around 1000 A/min. Note: To mix the TechniEtch™ TBR19 Concentrate correctly, a mixing ratio of 94 : 6 (94 wt % H2O2 and 6 wt % TBR19 concentrate additives) is recommended. This means that after mixing 500ml of TechniEtch™ TBR19 Concentrate with the corresponding amount of H2O2, you will obtain approx. 8 litres of the finished etching solution.   TBR19 (150°C 180s underetch smaller than 500nm) Product Properties High selectivity Significant reduction of undercut compared to conventional SC1 and HF Long bath life Tunable etch rate Selectivity TechniEtch™ TBR19 is compatible/etches selective to following materials: Metals: no attack on Cu, Al, Ni, Sn Metals: attack on TiN, TiW, Ti, SnPd Data on selectivity and compatibility are manufacturer information and do not claim to be complete. Please contact us for further details. Further Information MSDS: Safety Data TechniEtch TBR 19 (MOS) english Sicherheitsdatenblatt TechniEtch TBR 19 (MOS) german TDS: Technical Data Sheet TechniEtch TBR 19 (MOS) english Mixing Technical Data Sheet TechniEtch TBR 19 (MOS) english Specs: Specs TechniEtch TBR 19 (MOS) Application Notes: Wet Etching english Nasschemisches Ätzen german Wet Etching Metals english Nasschemisches Ätzen von Metallen german Further Information about Processing

TiW etch 100 Titan-Wolfram Etchant   General Information TiW etch 100 is applied as etchant for titanium-for the wet-chemical patterning of TiW layers with selectivity to metals like Au, Pt, Ni, Cr, Sn. Usual applications are found in the semiconductor or microsystem technology field for etching adhesion layers or diffusion barriers. Product Properties Low undercut (in the range of the layer thickness), minimum feature size < 1µm Selectivity to many materials, e.g. common metals used in electroplating industry Compatible to resist masking Selectivity TiW etch 100 is compatible/etches selective to following materials: Resists: common Novolak as masking resist (e.g. AZ® Photoresist) Metals: no attack on Au, Pt, Ni, Cr, Sn Metals: attack on TiW, Cu Cu impact at prolonged exposition Semiconductor materials: Si, SiO2, Si3N4 Data on selectivity and compatibility are manufacturer information and do not claim to be complete. Please contact us for further details. Etching Rate Under normal condition, the etching rate is around 1nm/sec (at room temperature). The mixed etching solution is stable over time and can be used multiple times depending on the requirements of application. It is recommended to dispose the solution at the latest, when the etching rate has changed by 20%. Further Information MSDS: Safety Data Sheet TiW etch 100 english Sicherheitsdatenblatt TiW etch 100 german TDS: Technical Data Sheet TiW etch 100 english Technisches Datenblatt TiW etch 100 german Application Notes: Wet Etching english Nasschemisches Ätzen german Wet Etching of Metals english Nasschemisches Ätzen von Metallen german Further Information about Processing

TiW etch 200 Titan-Wolfram Etchant   General Information TiW etch 200 is applied as etchant for titanium-for the wet-chemical patterning of TiW layers with selectivity to metals like Au, Pt, Ni, Cr. Usual applications are found in the semiconductor or microsystem technology field for etching adhesion layers or diffusion barriers. Product Properties Low undercut (in the range of the layer thickness), minimum feature size < 1µm Selectivity to many materials, e.g. common metals used in electroplating industry Compatible to resist masking Selectivity TiW etch 200 is compatible/etches selective to following materials: Resists: common Novolak as masking resist (e.g. AZ® Photoresist) Metals: no attack on Au, Pt, Ni, Cr Metals: attacked TiW, Cu Semiconductor materials: Si, SiO2, Si3N4 Data on selectivity and compatibility are manufacturer information and do not claim to be complete. Please contact us for further details. Etching Rate Under normal condition, the etching rate is around 5nm/min (at room temperature). The mixed etching solution is stable over time and can be used multiple times depending on the requirements of application. It is recommended to dispose the solution at the latest, when the etching rate has changed by 20%. Further Information MSDS: Safety Data Sheet TiW etch 200 EN Sicherheitsdatenblatt TiW etch 200 DE TDS: Technical Data Sheet TiW etch 200 EN Technisches Datenblatt TiW etch 200 DE Application Notes: Wet Etching Nasschemisches Ätzen Wet Etching of Metals Nasschemisches Ätzen von Metallen Further Information about Processing
