AZ ECI 3027 Photoresist - 3.785 l
Merck Performance Materials GmbH
AZ® ECI 3027 is a DNQ based thin positive resist with very high resolution potential for wet and dry etching applications.
The prices are visible after registration.
Send us an inquiry if you have any questions about articles, purchase quantities, delivery times or sample requests!
Product number:
1A003027
Manufacturer:
Merck Performance Materials GmbH
Product information "AZ ECI 3027 Photoresist - 3.785 l"
AZ® ECI 3027
High Resolution with Broad Process Window
General Information
The AZ® ECI 3000 series is a modern, state-of-the-art positive resist series. The resolution potential as well as the process stability allows feature sizes close to the theoretical minimum attainable with broadband (non-DUV) resists. AZ® ECI 3000 resists are a suitable series for both wet and dry chemical processes due to their good adhesion and thermal stability. The resist are available in three viscosity grades AZ® ECI 3007 (0.7 µm resist film thickness at 4000 rpm), AZ® ECI 3012 (1.2 µm) and AZ® ECI 3027 (2.7 µm). The very high resolution potential allows lateral structural sizes down to 300 nm and opens a comparatively large and stable process window at lower resolution requirements. These resists can be developed with NaOH, KOH or TMAH based developers.
900 nm resist lines with the AZ® ECI 3027 at approx. 2.7 µm resist film thickness.
Product Properties
- Very high resolution
- Optimized resist adhesion to all common substrate materials
- Steep resist-sidewalls and high aspect ratio for dry etching or ion implantation
- Broad process parameter window for stable and reproducible litho-processes
- Compatible with all common strippers (e.g. with AZ® 100 Remover, organic solvents or aqueous alkaline)
- g-, h- and i-line sensitive (approx. 320 - 440 nm)
- Resist film thickness range approx. 2 – 3.5 µm
Developers
If metal ion containing developers can be used, the NaOH-based AZ® 351B in a 1:4 dilution (for a required resolution < 1 µm 1:5 - 1:6 dilution recommended) is a suited developer. The KOH-based AZ® 400K (also 1:4 - 1:6 diluted) is possible, but due to its lower selectivity not recommended, if a high resolution or steep resist sidewalls are required. If metal ion free developers have to be used, we recommend the TMAH-based AZ® 326 MIF or AZ® 726 MIF developer, either undiluted, or - for maximum resolution - moderately 3:1 - 2:1 (3 parts Developer:1 part of DI-Water) diluted with water.
Removers
For non cross-linked resist films the AZ® 100 Remover, DMSO or other common organic solvents can be used as stripper. If the resist film is cross-linked (e.g. by high temperature steps > 140°C, during plasma processes such as dry etching or during ion implantation), we recommend the NMP-free TechniStrip P1316 as remover.
Thinning/ Edge Bead Removal
We recommend for thinning and edge bead removal the AZ® EBR Solvent or PGMEA. AZ® EBR Solvent 70/30 is possible as well for edge bead removal.
Further Information
MSDS:
Safety Data Sheet AZ® ECI 3027 Photoresist english
Sicherheitsdatenblatt AZ® ECI 3027 Fotolack german
TDS:
Technical Data Sheet AZ® ECI 3000 Series english
Application Notes:
Further Information about Photoresist Processing
