AZ Developer 1:1 - 5.00 l
Merck Performance Materials GmbH
AZ® Developer 1:1 is a ready-to-use product and a sodium metal silicate based developer formulation for positive and image reversal resists with full compatibility to aluminum.
The prices are visible after registration.
Send us an inquiry if you have any questions about articles, purchase quantities, delivery times or sample requests!
Product number:
1000115
Manufacturer:
Merck Performance Materials GmbH
Product information "AZ Developer 1:1 - 5.00 l"
AZ® Developer 1:1
Inorganic Developers
General Information
AZ® Developer 1:1 is a ready-to-use product and is a 1:1 dilution of AZ Developer. The developer is optimized for minimum Al attack. It is an odourless, aqueous, inorganic, alkaline solution, which is compatible with batch and in-line developing processes. AZ® Developer 1:1 is for high contrast. The dark erosion of AZ® Developer 1:1 is slightly higher as compared to other developers. AZ® Developer 1:1 can be used in combination with most families of AZ® Photoresists (i.e. AZ® 1500, AZ® ECI3000 and AZ® 4500 or AZ® PL177). AZ® Developer 1:1 displays the lowest aluminium etch rate (it is more or less zero!) of all AZ® Developer 1:1 types and is ideal for metal levels.
Further Information
MSDS:
Safety Data Sheet AZ® Developer 1:1 english
Sicherheitsdatenblatt AZ® Developer 1:1 german
TDS:
Technical Data Sheet AZ® Developer 1:1 english
Application Notes:
Development of Photoresist english
Entwicklung von Fotolack german
